42SH7DB-M component-copyModelName
42'' 700 nits FHD Standard Signage

Key Features

Choose your Size

Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

42" 700 nits FHD Standard Signage
Find a Dealer
Close
PANEL
  • Screen Size
    41.92" (1064.67mm) diagonal
    Resolution
    1,920 x 1,080 (FHD)
  • Brightness (Module, Typ., cd/m²)
    700
CONNECTIVITY - INTPUT
  • HDMI
    Yes (1)
    DP
    Yes (1)
  • DVI
    Yes (1)
    Analog (RGB)
    Yes (1)
  • Audio
    Yes (1)
    External Control (RS232C(Phone Jack Type))
    Yes (1)
  • External Control (RJ45)
    Yes (1)
    External Control (IR receiver)
    Yes (1)
  • External Control (Pixel Sensor(Optional))
    Yes
    USB
    Yes (1)
CONNECTIVITY - OUTPUT
  • DP Out
    Yes
    Audio Out
    Yes
  • Externel Speaker Out
    Yes (1, L/R)
    External Control (RS232C OUT)
    Yes (1)
PHYSICAL SPECIFICATION
  • Bezel Width
    7.4mm (T/L/R/U even)
    Monitor Dimension (W x H x D)
    94.9cm X 55.5cm X 3.2cm
  • Weight (Head)
    12.5kg
    VESA™ Standard Mount Interface
    400mm x 400mm
MEDIA PLAYER COMPATIBILITY
  • OPS Type Compatible
    Yes
    External Media Player Attatchable
    Yes (MP500/MP700)
SOFTWARE COMPATIBILITY
  • SuperSign-w lite
    Yes
    SuperSign-c
    Yes
ACCESSORY
  • Basic
    Remote Controller (include battery 2ea), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, IR Receiver
    Optional
    SP-2100 (External Speaker), ST-200T, LSW440S, AN-WF500 (WiFi USB Dongle), KT-OPSA (OPS Kits), KT-SP0 (Pixel Sensor)
GENERAL
  • Region
    Global

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
