All-in-one Premium Series

Key Features

Choose your Pitch

component-OBScountrySelectDesc

All-in-one Premium Series
PHYSICAL PARAMETER
  • Pixel Configuration
    3 in 1 SMD
    Pixel Pitch (mm)
    1.50
  • Screen Resolution (W × H)
    1,920 × 1,080
    Screen Dimension (W × H × D,mm)
    2,880 × 1,620 × 128.5 mm (w / o Screen Frame)
  • Screen Weight (kg)
    162.1 kg (w / o Screen Frame)
    No. of Cabinet per Screen (W × H)
    3 × 3
  • No. of Modules per Cabinet (W × H)
    4 × 3
    Cabinet Resolution (W × H)
    640 × 360
  • Cabinet Dimensions (W × H × D)
    960 × 540 × 128.5 mm
    Cabinet Surface Area (m²)
    0.52
  • Weight per Cabinet (kg/unit)
    Main: 19.3
    Secondary: 17.8
    Weight per Square Meter (kg/m²)
    34.7
  • Physical Pixel Density (pixels/m²)
    444,444
    Flatness of Cabinet
    ± 0.2 mm
  • Cabinet Material
    Front: Die Casting Aluminum
    Rear: PC+ABS
    Service Access
    Front and Rear
OPTICAL PARAMETER
  • Brightness (Max.)
    500 nit
    Color Temperature
    6,500
  • Visual Viewing Angle (Horizontal)
    160
    Visual Viewing Angle (Vertical)
    140
  • Brightness Uniformity
    95%
    Color Uniformity
    ±0.015Cx,Cy
  • Contrast Ratio
    5,000 : 1
    Processing Depth
    16 bit
  • HDR Compatibility
    HDR10, HDR10 Pro
    ※ HDR10 Pro is LG's own HDR solution to process HDR signal by using enhanced dynamic tone mapping.
ELECTRICAL PARAMETER
  • Power Consumption (W/Screen, Max.)
    2,900
    Power Consumption (W/Screen, Avg.)
    980
  • Power Consumption (W/m², Max.)
    622
    Power Supply (V)
    AC 100 - 240 V
  • Frame Rate (Hz)
    50 / 60
    Refresh Rate (Hz)
    3,840
  • Sound Output (Max.)
    162W
OPERATION CONDITIONS
  • Lifetime (Hours to Half Brightness)
    100,000
    Operating Temperature (°C)
    0°C to 40°C
  • Operating Humidity
    10 % to 80 %
CONNECTIVITY(EMBEDDED CONTROLLER)
  • Video Inputs
    HDMI In (3), DP In, USB 2.0
    Control
    RJ45 In, RS232C In/out
  • Special Features
    Temperature Sensor, Ambient Light Sensor, Crestron Connected®(Network based control)
CERTIFICATION
  • Safety
    IEC 60950-1 / EN 60950-1 / UL 60950-1
    EMC
    FCC Class A / CE / KC
  • Environment
    RoHS
ACCESSORY
  • Basic
    Data Cable, LAN Cable, Power Cord, RS232C Gender (9 Pin to Phone Jack), Remote Controller, IR Receiver, Manual
    Optional
    Screen Frame (ACC-LAASF15), Floor Stand (ST-1300F)
SW
  • Platform
    webOS 4.0
    Support
    Signage365Care (The availability differs by region), SuperSign CMS, LED Assistant
