LSBF Indoor LED Series
Find a Dealer

LSBF Indoor LED Series

There are large LED displays installed across three floors of a large shopping mall, prominently showcasing perfume advertisements. There are large LED displays installed across three floors of a large shopping mall, prominently showcasing perfume advertisements.
* All images in this page are for illustrative purposes only.
LSBF has a brightness of 600 nits, so it is clearly visible, even under strong light. LSBF has a brightness of 600 nits, so it is clearly visible, even under strong light.

Brightness

With a great brightness of 600 nits, it clearly delivers content and attracts public attention, making it ideal for achieving bright indoor visibility.
LSBF consists of a total of 8 modules that create a single cabinet. LSBF consists of a total of 8 modules that create a single cabinet.

Improved Flatness and Easy Maintenance

LSBF is composed of four LSBE modules that form one cabinet with two modules each, allowing it to create a seamless screen. Also, it allows for easy maintenance.
The frame of LSBF is composed of aluminum. The frame of LSBF is composed of aluminum.

Durable Frame Design

LSBF incorporates an aluminum cabinet that enhances durability, and its high-strength frame, surpassing that of plastic, allows for stable operation.

54" & 27" Combination Installation Available

The LSBF (54") and LSBE (27") models, sharing the same product platform, provide flexible matrix combinations for various spatial configurations. The compatibility between the 54" and 27" models enables versatile sizing options according to space requirements, allowing for installation.
The 27" LSBE and the 54" LSBF are compatible and installed on the shopping mall wall in appropriate sizes. The 27" LSBE and the 54" LSBF are compatible and installed on the shopping mall wall in appropriate sizes.

Compatibility with LG Software Solutions

When connected with LG's CVBA system controller, the LSBF series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.
The LG employee is remotely monitoring the LSBF series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables LSBF series to be compatible with LG software solutions. The LG employee is remotely monitoring the LSBF series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables LSBF series to be compatible with LG software solutions.
* The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
* The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
* Actual GUI may vary in different webOS versions.
* LG Software solutions needs to be purchased separately.
Close
PHYSICAL PARAMETERS
  • Pixel Configuration
    Single SMD
    Pixel Pitch(mm)
    2.50
  • Module Resolution (WxH)
    120x135
    Module Dimensions(WxH,mm)
    300x337.5x13
  • Weight per Module (kg)
    0.95
    No. of Modules per Cabinet (WxH)
    4 x 2
  • Cabinet Resolution (WxH)
    480x270
    Cabinet Dimensions (W x H x D, mm)
    1200x675x72
  • Cabinet Surface Area (㎡)
    0.810
    Weight per Cabinet (kg/unit)
    23.0
  • Weight per Square Meter (kg/m²)
    28.0
    Physical Pixel Density (pixels/m²)
    160,000
  • Flatness of Cabinet (mm)
    ±0.3
    Cabinet Material
    Die-casting Aluminum
  • Service access
    Front
OPTICAL SPECIFICATIONS
  • Max Brightness (After Calibration, nit)
    600
    Color Temperature (K)
    3,000 - 10,000
  • Visual Viewing Angle (Horizontal)
    160
    Visual Viewing Angle (Vertical)
    150
  • Brightness Uniformity
    97%
    Color Uniformity
    ±0.003Cx,Cy
  • Contrast Ratio
    5,000:1
    Processing Depth (bit)
    14
ELECTRICAL SPECIFICATIONS
  • Power Consumption (W/Cabinet, Max.)
    372
    Power Consumption (W/Cabinet, Avg.)
    145
  • Power Consumption (W/m², Max.)
    460
    Heat Dissipation (BTU/h/Cabinet, Max.)
    1,270
  • Heat Dissipation (BTU/h/Cabinet, Avg.)
    495
    Heat Dissipation (BTU/h/m², Max.)
    1,570
  • Power Supply (V)
    100 to 240
    Frame Rate (Hz)
    50 / 60
  • Refresh Rate (Hz)
    3,840
OPERATION SPECIFICATIONS
  • LED Lifetime (Half brightness)
    100,000
    Operating Temperature(℃)
    -20℃ to +40℃
  • Operating Humidity
    10~80%RH
    IP rating Front
    IP50
  • IP rating Rear
    IP50
Standard
  • Certification
    CE, FCC, cTUVus, CB, KC, CCC
Environment
  • Environment
    RoHS, REACH
CONTROLLER
  • Controller
    CVBA
SERIES
  • Series
    LSBF

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
