LG Indoor LED Series, 2024

LSGA Indoor LED Series

At the airport, a massive fit-to-wall LED screen is installed, and the screen displays flight times and Ads clearly. At the airport, a massive fit-to-wall LED screen is installed, and the screen displays flight times and Ads clearly.
* All images in this page are for illustrative purposes only.

Fast Installation

Various factors such as safety knobs, fast locks, handles, and positioning pins facilitate the installer in smoothly setting up and dismantling LED screens without the requirement of extra tools.
The cabinet parts, including 'Safety Knobs', 'Easy Handle', 'Fast Lock & One Hand Operation', and 'Positioning Pins', are depicted in an enlarged manner. The cabinet parts, including 'Safety Knobs', 'Easy Handle', 'Fast Lock & One Hand Operation', and 'Positioning Pins', are depicted in an enlarged manner.

Easy Maintenance

The LSGA series features a lock fixing method that requires no additional tools, simplifying the process of replacing LED modules or power/data units and resulting in time and cost savings for maintenance.
It is demonstrating that a simple Lock Fixing method allows for convenient replacement of the cabinet's Power/Data Unit. It is demonstrating that a simple Lock Fixing method allows for convenient replacement of the cabinet's Power/Data Unit.
The screen is tailored to fit the wall, utilizing two different cabinet sizes. The screen is tailored to fit the wall, utilizing two different cabinet sizes.

Two Cabinet Options

The LSGA series offers two cabinet sizes to accommodate customer demands for various screen sizes.
Capable of front and rear installation depending on the customers' needs. Capable of front and rear installation depending on the customers' needs.

Front and Rear Serviceability

The product offers either front access or rear access, allowing customers to choose installation options according to their environment and minimizes limitations in installation and maintenance.
Close
PHYSICAL PARAMETERS
  • Pixel Configuration
    Single SMD
    Pixel Pitch(mm)
    2.6
  • Module Resolution (WxH)
    96x96
    Module Dimensions(WxH,mm)
    250x250
  • Weight per Module (kg)
    0.55
    No. of Modules per Cabinet (WxH)
    2x4
  • Cabinet Resolution (WxH)
    192x384
    Cabinet Dimensions (W x H x D, mm)
    500x1,000x90
  • Cabinet Surface Area (m²)
    0.5
    Weight per Cabinet (kg/unit)
    10
  • Weight per Square Meter (kg/m²)
    20
    Physical Pixel Density (pixels/m²)
    147,456
  • Flatness of Cabinet (mm)
    ±0.1
    Cabinet Material
    Magnalium
  • Service access
    Front & Rear
OPTICAL SPECIFICATIONS
  • Max Brightness (After Calibration, nit)
    800
    Color Temperature (K)
    3,200~9,300
  • Visual Viewing Angle (Horizontal)
    160
    Visual Viewing Angle (Vertical)
    140
  • Brightness Uniformity
    0.98
    Color Uniformity
    ±0.003Cx,Cy
  • Contrast Ratio
    6,500:1
    Processing Depth (bit)
    14
ELECTRICAL SPECIFICATIONS
  • Power Consumption (W/Cabinet, Max.)
    196
    Power Consumption (W/Cabinet, Avg.)
    66
  • Power Consumption (W/m², Max.)
    392
    Heat Dissipation (BTU/h/Cabinet, Max.)
    535
  • Heat Dissipation (BTU/h/Cabinet, Avg.)
    180
    Heat Dissipation (BTU/h/m², Max.)
    1,070
  • Power Supply (V)
    100 to 240
    Frame Rate (Hz)
    50 / 60
  • Refresh Rate (Hz)
    3,840
OPERATION SPECIFICATIONS
  • LED Lifetime (Half brightness)
    100,000
    Operating Temperature(℃)
    -10℃ to +40℃
  • Operating Humidity
    10~80%RH
    IP rating Front
    IP40
  • IP rating Rear
    IP20
Standard
  • Certification
    CE, FCC, cTUVus, CB
Environment
  • Environment
    RoHS, REACH
CONTROLLER
  • Controller
    CVGA

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
