All New Air Conditioner, LG DUALCOOL Inverter
Dimensions
CAPACITY
-
- Cooling - Min ~ Rated ~ Max(kW)
- 0.90 / 5.27 / 6.33
- Cooling - Min ~ Rated ~ Max(Btu/h)
- 3,070 / 18,000 / 21,600
-
- Cooling (T3) - Min ~ Rated ~ Max(kW)
- 0.79 / 4.78 / 5.56
- Cooling (T3) - Min ~ Rated ~ Max(Btu/h)
- 2,700 / 16,300 / 19,000
POWER INPUT
-
- Cooling - Min ~ Rated ~ Max(W)
- 352 / 1,645 / 3,080
- Cooling (T3) - Min ~ Rated ~ Max(W)
- 352 / 2,010 / 3,080
RUNNING CURRENT
-
- Cooling - Min ~ Rated ~ Max(A)
- 1.60 / 7.40 / 15.40
- Cooling (T3) - Min ~ Rated ~ Max(A)
- 1.60 / 9.40 / 15.40
EER
-
- EER(W/W)
- 3.21
- EER((Btu/h)/W)
- 10.94
EER(T3)
-
- EER (T3)(W/W)
- 2.38
- EER (T3)((Btu/h)/W)
- 8.11
ENERGY LABEL GRADE
-
- Cooling / Heating
- 3 / -
ANNUAL ENERGY CONSUMPTION
-
- Cooling / Heating
- 4,442 / -
POWER SUPPLY
-
- Ø / V / Hz
- 1, 220-240, 50
AVAILABLE VOLTAGE RANGE
-
- Available Voltage Range(V)
- 187 ~ 276
POWER FACTOR
-
- Cooling / Heating(%)
- 96.7 / -
MOISTURE REMOVAL
-
- Moisture Removal(l/h)
- 2.5
INDOOR
-
- Air Flow Rate - Cooling, Max / H / M / L(㎥/min)
- 18.5 / 14.0 / 12.5 / 10.0
- Sound Pressure Level - Cooling, Max / H / M / L / SL(dB(A))
- - / 44 / 41 / 37 / 28
-
- Dimensions (W × H × D) - Net(mm)
- 998 × 330 × 210
- Dimensions (W × H × D) - Shipping(mm)
- 1145 × 395 × 300
-
- Weight - Net(kg)
- 11.6
- Weight - Shipping(kg)
- 13.4
-
- Exterior Color Code
- Munsell 7.5BG 10/2 (RAL 9016)
OUTDOOR
-
- Air Flow Rate - Max(㎥/min)
- 49.0
- Sound Pressure Level - Cooling, Rated(dB(A))
- 52
-
- Dimensions (W × H × D) - Net(mm)
- 870 × 650 × 330
- Dimensions (W × H × D) - Shipping(mm)
- 1026 × 693 × 446
-
- Weight - Net(kg)
- 43.0
- Weight - Shipping(kg)
- 47.0
-
- Max. Fuse Size(A)
- 25
- Exterior Color Code
- Munsell 9.54Y 8.34/1.31 (RAL 9001)
-
- Operation Range - Cooling(℃ DB)
- 18 ~ 54
COMPRESSOR
-
- Type
- Dual Inverter Compressor™
- Model
- GAT156MAD
-
- Motor Type
- BLDC
- Oil Type / Maker
- POE (RB68A) / Sun Oil or Jx Nippon
-
- Oil Charge (cc)
- 400
- Manufacturer / Country of Origin
- LG Electronics / China
FAN(INDOOR)
-
- Type
- Cross Flow Fan
- Motor Output (W)
- 30
FAN(OUTDOOR)
-
- Type
- Propeller Fan
- Motor Type
- BLDC
-
- Motor Output (W)
- 85
- Motor Insulation
- Class E
-
- Motor Enclosure / Ingress Protection
- TEAO / IPX4
HEAT EXCHANGER
-
- Evaporator - Material, Tube / Fin
- Cu / Al
- Evaporator - (Φ x Row x Column x FPI/FPDM x L) x Qty.(W)
- (Φ7 x 2 x 16 x 20FPI x 744) x 1
-
- Evaporator - Corrosion Protection
- PCM
- Condenser - Material, Tube / Fin
- Cu /Al
-
- Condenser - (Φ x Row x Column x FPI/FPDM x L) x Qty.(#3)
- (Φ7 x 2 x 28 x 18FPI x 940) x 1
- Condenser - Corrosion Protection
- Gold Fin™
CIRCUIT BREAKER
-
- Circuit Breaker(A)
- 25
POWER SUPPLY CABLE
-
- Power Supply Cable(No. × ㎟)
- 3 × 2.5
POWER SUPPLY TO UNIT
-
- Power Supply to Unit
- Outdoor
POWER AND COMMUNICATION CABLE
-
- Power and Communication Cable(No. × ㎟)
- 4 × 1.0
PIPING
-
- Size - Liquid(mm)
- Ø 6.35
- Size - Gas(mm)
- Ø 12.7
-
- Connections Method - Indoor / Outdoor
- Flared / Flared
DRAIN HOSE SIZE
-
- O.D, I.D(mm)
- 21.5, 16.0
BETWEEN INDOOR & OUTDOOR
-
- Piping Length - Min / Standard / Max(m)
- 3 / 5 / 20
- Piping Length - No Charge(m)
- 7.5
-
- Max. Elevation Difference(m)
- 15
REFRIGERANT
-
- Type
- R410A
- Pre Charge(g)
- 1350
-
- Additional Charge(g/m)
- 20
- Control
- Capillary
TOOL CODE(CHASSIS)
-
- Indoor / Outdoor
- SK / U24A
FEATURE
-
- Air Flow - 4way Swing
- Yes
- Air Flow - Jetcool
- Yes
-
- Air Flow - Comfort Air
- Yes
- Air Purifying - Dual Protection Filter
- Yes
-
- Air Purifying - Auto Cleaning
- Yes
- Convenience - Comfort Sleep
- Yes
-
- Convenience - Smart Diagnosis
- Yes
