Discontinued
Cooling only

Key Features

component-OBScountrySelectDesc

Cooling only
DIMENSION
  • Indoor (W*H*D)(mm)
    1209*346*237
    Indoor (W*H*D)(inch)
    47.6*13.6*9.3
  • Outdoor (W*H*D)(mm)
    870*800*320
    Outdoor (W*H*D)(inch)
    34.3*31.5*12.6
FILTER
  • Prefilter(washable/anti-fungus)
    Yes
HIGHLIGHTS
  • Cooling (Min / Rated / Max) T1
    7.03 KW , 24,000 Btu/h
    Power Input (Cooling) T1-W
    2340
  • Power Supply
    1 / 220-240 / 50 - Ø / V / Hz
    Running Current (Cooling) T1-A
    10.5
NET WEIGHT
  • Indoor (kg(lbs))
    17 (36.4)
    Outdoor (kg(lbs))
    60 (132.3)
OPERATION RANGE
  • Cooling (outdoor) °C(°F)
    21~54(69.8~129.2)
OTHER FUNCTIONS
  • Additional Refrigerant charge
    20 g/m
    Circuit Breaker
    20 A
  • Max. Elevation Difference
    15 (49.2) m(ft)
    Max. Piping Length
    20 (65.6) m(ft)
  • Moisture Removal
    3.8 l/h
    Refrigerant & Charge
    R22, 1,150 (40.56) g(oz)
PERFORMANCE
  • Air Flow Rate (Indoor, Max)
    22.0 (777) m3/min(CFM)
    Air Flow Rate (Outdoor, Max)
    58.0 (2,048) m3/min(CFM)
  • EER
    3.0 T1-W/W , 10.3 T1-Btu/h.W
    Noise Level © (Indoor,H / M / L / LL)
    52 / 46 / 41 / dB(A)±3
  • Noise Level © (Outdoor, Max)
    56 dB(A)±3
PIPING CONNECTIONS
  • Liquid Side (mm(in))
    9.52 (3/8)
    Gas Side (mm(in))
    15.88(5/8)
