DH6631T component-copyModelName
DVD Home Theatre System

Key Features

Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

DVD Home Theatre System
Close
PHYSICAL - SIZE(W X H X D)MM
  • Main
    360x60x316
    Front Speaker
    250X1150X250
  • Center Speaker
    260x92x73
    Rear Speaker
    250X1150X250
  • Subwoofer
    133x352x325
AMPLIFIER
  • CH
    5.1
    Power Output - Total
    1000W (Peak :1100W_LGEAF_only)
  • Power Output - Front L/R
    167WX2 (Peak : 184WX2 )
    Power Output - Center
    167W (Peak : 184W)
  • Power Output - Surround L/R
    167WX2 (Peak : 184WX2 )
    Power Output - Sub-Woofer
    167W(Passive) (Peak : 184W)
DESIGN(MAINSET)
  • Front & Rear cabinet (tray)
    Yes
HOME MENU
  • Home Menu
    Yes
IN & OUT FRONT
  • Display
    FLD
    USB
    1
  • Audio In - Portable In
    Yes
IN & OUT R/PANEL
  • Video Out - Composite
    Yes
    Audio Input - Audio L/R
    Yes
  • Audio Input - Optical
    1
    HDMI - Out
    1
  • Radio Antenna - FM
    Yes
    Speaker Terminal - Composing of channel
    5.1
  • Speaker Terminal - Terminal Type
    Push in (Spring)
CONVENIENCE
  • SIMPLINK
    Yes
    Speaker Level Trim
    Yes
  • Speaker Distance (channel delay)
    Yes
    Test Tone
    Yes
  • Mute
    Yes
    A/V Sync Delay(Audio Delay)
    Yes
  • Dimmer
    Yes
    Sleep
    Yes
  • Volume on TV
    Yes
    USB Direct Recording
    Yes
  • TV Sound (direct key) / TV Sound connect (Auto PWR on/off by optical)
    Yes
    Dynamic Range Control On/Off
    Yes
  • Bluetooth (Rx / Tx)
    Yes / Yes
    Karaoke - Mic Volume / Echo Volume
    Yes
  • Karaoke - Fanfare
    Yes
    Karaoke - Scoring
    Yes
  • Karaoke - Howlling Canceller
    Yes
DISC & AV FORMAT
  • Playable Disc Type - DVD(NTSC)
    Yes
    Playable Disc Type - DVD(PAL)
    Yes
  • Playable Disc Type - DVD-R
    Yes
    Playable Disc Type - DVD-RW(Video)
    Yes
  • Playable Disc Type - DVD+R
    Yes / Yes
    Playable Disc Type - DVD+RW(Video mode)
    Yes
  • Playable Disc Type - Video CD/Super VCD
    Yes / Yes
    Playable Disc Type - Audio CD
    Yes
  • Playable Disc Type - CD-R/CD-RW
    Yes
    Video Format - MPEG2
    Yes
  • Video Format - DivX
    Yes
    Audio Format - LPCM
    LPCM
  • Audio Format - Dolby Digital
    Yes
    Audio Format - MPEG 1/2 L2
    Yes
  • Audio Format - MP3/ID3 Tag
    Yes
    Audio Format - WMA
    Yes
  • Graphics/Subtitle Format
    2bit/ 8bit Sub-picture / Text-based Subtitle
    GUI/ Menu
    Option
  • Video DAC
    148MHZ/12bit
    NTSC/PAL Hz
    60Hz / 50Hz
  • Resolution
    upto 1080p24/60Hz
    VBI - WSS/CGMS-A/Closed Caption/Macrovsion
    Yes
  • NTSC⇔PAL Conversion
    Yes
    Last Scene memory
    Yes
DISC(BD, DVD, CD)PLAYBACK SPECIFICATION
  • Screen Saver
    Yes
    Power Resume
    Yes
  • Parental Lock
    Yes
    DVD - 1080p Upscaling
    Yes
  • Trick Play - Fast Forward
    Yes
    Trick Play - Fast Back
    Yes
  • Trick Play - Forword Slow
    Yes
    Trick Play - Reverse Slow
    Yes
  • Trick Play - Pause
    Yes
    Trick Play - Forward Step
    Yes
  • Search - Title/Track
    Yes
    Search - Chapter
    Yes
  • Search - Time
    Yes
    Repeat Play - Title/Track
    Yes
  • Repeat Play - Chapter
    Yes
    Resume Stop
    Yes
  • Play Mode - Random
    Yes
    Marker Play
    Yes
POWER
  • Power Off Consumption
    0.18
    Power Consumption
    100
RADIO
  • Tuner Type
    PLL
    Tuning Up/Down
    Yes
  • Preset Up/Down
    Yes
    Band(FM)
    Yes
  • Preset Memory
    50 Station
SPEAKER
  • Front - Model Name
    S63T2-S
    Front - SPL
    81.5dB
  • Front - System
    Closed type
    Front - Woofer Unit
    3" Yellow Paper
  • Front - Impedance
    3Ω
    Front - Magnetic Shielding
    Perfect-Shield
  • Rear - Model Name
    S63T2-S
    Rear - SPL
    81.5dB
  • Rear - System
    Closed Type
    Rear - Woofer Unit
    3" Yellow Paper
  • Rear - Impedance
    3Ω
    Rear - Magnetic Shielding
    Shielded Type
  • Center - Model Name
    S63S2-C
    Center - SPL
    79.0dB
  • Center - System
    Closed type
    Center - Woofer Unit
    3" Yellow Paper
  • Center - Impedance
    3Ω
    Center - Magnetic Shielding
    Shielded Type
  • Subwoofer - Model Name
    S63T4-W
    Subwoofer - SPL
    83dB
  • Subwoofer - System
    Bass Reflex
    Subwoofer - Woofer Unit
    7" Cone
  • Subwoofer - Impedance
    3Ω
    Subwooder - Magnetic Shielding
    Non-Shield
FEATURE LIST - ACCESSORY KIT
  • Instruction Manual
    Printing Book
    Simple Manual
    Yes
  • Remote Control Unit - Type
    CB1
    Remote Control Unit - Unified
    Yes
  • Remote Control Unit - Battery(Size)
    AAA*1
    Batteries (Remote Controller)
    Yes
  • FM Antenna
    Yes
    Speaker Cable
    Yes (6 EA)
  • Warranty Card
    Yes
    RCA Code(Video), Yellow, 1P
    Yes
  • HDMI Cable
    Yes
    Carton Box Type(Tip on, Offset, Flexo)
    Tip on
