All Spec
PANEL
-
Screen Size
65" (164cm)
-
Panel Technology
OLED (Wallpaper)
-
Resolution
3,840 x 2,160 (4K UHD)
-
Brightness (cd/m²)
400
-
Static (Panel) Contrast Ratio
1,400:1
-
Viewing Angle (H x V)
120 x 120
-
Response Time (G to G, ms)
5
BROADCASTING SYSTEM
-
Analogue
PAL/SECAM
-
Digital
DVB-T2/C
VIDEO
-
XD Engine
Yes
-
Aspect Ratio
5 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom)
-
HDR 10 / HDR Dolby Vision
Yes / Yes
AUDIO
-
Audio Output
30W + 30W (TBD)
-
Speaker System
2.2.2 ch
-
Sound Mode
6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)
-
Clear Voice
Clear Voice III
-
Dolby Atoms
Yes
-
Adaptive Sound Control
Yes
-
One Touch Sound Tuning
Yes
-
Audio Channel
Yes
HOSPITALITY SOLUTION
-
Solution Type
Pro:Centric (Smart, Direct, V)
-
Data Streaming (IP & RF)
Yes
-
RF
1 Tuner
-
HCAP (GEM/FLASH/HTML) ※ Service Carousel (TLL/XML)
GEM / Flash / HTML5
-
Pro:Centric Application (version)
PCA 3.8
-
DRM
Pro:Idiom
SMART FEATURE
-
Smart Feature
webOS 4.0, Quick Menu 2.0, Commercial Smart Home, Gallery Mode, Quick Access, Voice Recognition, Web Browser, Pre-loaded App, SDP Server Compatibility, Magic Remote Compatibility (AN-MR18BA_Commercial only), Soft AP, Wi-Fi (ac), Screen Share (Miracast), Smart Share (DLNA), DIAL, Bluetooth Audio Playback, LG Sound Sync/bluetooth, Mobile Connection Overlay, Music Player
FUNCTION
-
Function
EzManager, USB Cloning, Wake on RF, WOL, SNMP, Diagnostics, SI Compatible, HTNG-CEC (1.4), HDMI-CEC (1.4), IR Out, Multi IR Code, Auto Off / Sleep Timer, Smart Energy Saving, Motion Eye Care, Teletext, BEACON
HOSPITALITY FEATURES
-
Hospitality Features
Hotel Mode / PDM / Installer Menu, Lock mode (Limited), Welcome Screen, Insert Image, One Channel Map, External Speaker Out, Instant ON, External Power, VLAN ID, RJP Interface, RJP Compatibility, Clock (World Clock / Alarm), 360 Viewer
JACK INTERFACE
-
Set Side
-
-
Set Rear
RF In, AV In (Phone Jack), Component in (Y,Pb,Pr-Video), Digital Audio Out (Optical), HDMI/HDCP Input 2.0 (2), USB 2.0 (2), RS-232C (Control & Service), Clock Interface (D-sub 15pin), CI Slot, RJ45 (2), External Speaker Out
DIMENSION(UNIT: MM)
-
Vesa
N/A (Wallpaper)
-
W x H x D / weight (TV only)
(Head) 1,446 x 823 x 3.85 / 6.7kg
-
W x H x D / weight (Including AIO box, wall mount)
(Head) 1,446 x 823 x 3.85 (AIO BOX) 1,260 x 78 x 198
/ (Head, AIO Box, Wall mount) 6.7kg, 10.0kg, 2.3kg -
W x H x D / weight (Packing)
1,641 x 952 x 288 / 32.1kg
POWER(UNIT : WATTS)
-
Voltage, Hz
100 ~ 240V, 50/60Hz
-
Max
470
-
Typical
275
-
Energy saving (Min/Med/Max)
200 / 143 / 72
-
Stand-by
0.5W↓
