All Spec
PANEL
-
Screen Size
75"
-
Panel Technology
IPS
-
Aspect Ratio
16:9
-
Native Resolution
3,840 × 2,160
-
Brightness (Typ.)
350cd/m²
-
Contrast Ratio
1,200:1
-
Viewing Angle (H x V)
178 x 178
-
Response Time
6ms (G to G)
-
Surface Treatment (Haze)
Haze 3%
-
Life Time (Typ.)
50,000Hrs
-
Operation Hours
24Hrs
-
Orientation
Landscape & Portrait
CONNECTIVITY
-
Input
HDMI (3), DP, DVI-D, Audio, USB 2.0 (2)
-
Output
DP, Audio (Off/Fixed/Variable)
-
External Control
RS232C In/out, RJ45 In, IR In
PHYSICAL SPECIFICATION
-
Bezel Colour
Black
-
Bezel Width
14.9mm (Even)
-
Monitor Dimension (W x H x D)
1,682.4 x 960.3 x 57.9 mm (w/o Handle and Logo)
-
Carton Dimensions (W x H x D)
1,816 x 1,123 x 228 mm
-
Weight (Head)
41.5kg
-
Packed Weight
49kg
-
VESATM Standard Mount Interface
600 x 400 mm
SPECIAL FEATURES
-
Special Features
Internal Memory (System 4GB + Available 3.6GB), Wi-Fi Built-in, Temperature Sensor, Auto Brightness Sensor, webOS 4.0, USB Auto Playback, Local Contents Scheduling, Group Manager, Fail Over ,Image Customisation (Booting Logo, No Signal), Content Sync (RS232C, Local Network), PIP/PBP(4), Screen Share, Play via URL, Content Rotation, Tile Mode Setting (Max. 15 x 15), Setting Data Cloning (RS232C, Network, USB), Firmware Update by Network, SNMP, ISM Mode, Control Manager, Crestron Connected Ⓡ 1), Cisco Compatibility 2), DPM, Smart Energy Saving, PM Mode, Wake on LAN, Beacon, HDMI-CEC 3), SI Server Setting, webRTC
POWER
-
Power Supply
100-240V~, 50/60Hz
-
Power Type
Built-In Power
-
Power Consumption - Typ.
160W
-
Power Consumption - Max.
185W
STANDARD(CERTIFICATION)
-
Safety
CB / NRTL
-
EMC
AS/NZS CISPR32,RCM(Class A)
-
ErP / Energy Star
Yes(EU Only) / Yes (Energy Star 8.0)
SOFTWARE COMPATIBILITY4)
-
Content Management Software
SuperSign CMS
-
Control and Monitoring Software
SuperSign Control+/Control
ACCESSORIES
-
Basic
Remote Controller (2ea Batteries Included), Power Cord, QSG, DP Cable (1.8M), Regulation Book, Phone to RS232C Gender
-
Optional
OPS Kit (KT-OPSF), Wall Mount (LSW640A/B)
