High Brightness Video Wall
All Spec
PANEL
-
Screen Size
55”
-
Panel Technology
IPS
-
Aspect Ratio
16 : 9
-
Native Resolution
1,920 x 1,080 (FHD)
-
Brightness
1,500 cd/m2
-
Contrast Ratio
1,300:1
-
Dynamic CR
500,000:1
-
Viewing Angle (H x V)
178 x 178
-
Response Time
8 ms (G to G)
-
Surface Treatment
Hard Coating (2H), Anti-glare Treatment of the Front Polariser (Haze 3% Typ.)
-
Operation Hours
24 Hours
-
Orientation
Landscape & Portrait
CONNECTIVITY
-
Input
HDMI, DP, DVI-D, RGB, Audio In, USB 3.0
-
Output
DP, Audio Out
-
External Control
RS232C In/out, RJ45 In/out, IR Receiver In
PHYSICAL SPECIFICATION
-
Bezel Width (B to B)*
2.25 mm (L/T) / 1.25 mm (R/B)
-
Monitor Dimension (W x H x D)
1,213.4 x 684.2 x 92.8 mm
-
Weight (Head)
23.5 kg
-
Carton Dimensions (W x H x D)
1,353 x 855 x 263 mm
-
Packed Weight
36.6 kg
-
VESATM Standard Mount Interface
600 x 400 mm
SPECIAL FEATURES
-
SPECIAL FEATURES
Temperature Sensor, Tile Mode (Up to 15 x 15), Natural Mode @Tile Mode, ISM Method, DPM Select, Energy Saving, Smart Energy Saving, File Play with USB, Internal memory (8GB, System 4GB + Available 4GB), USB Cloning, Contents Scheduling, Fail Over, Media Share
ENVIRONMENT CONDITIONS
-
Operation Temperature Range
0°C ~ 40°C
-
Operation Humidity Range
10% ~ 80%
POWER
-
Power Supply
100-240V~, 50/60Hz
-
Power Type
Built-In Power
-
Power Consumption-Typ./Max
250 W / 280 W
-
Power Consumption-Smart Energy Saving
213 W
STANDARD(CERTIFICATION)
-
Safety
AS/NZS 60950,CB Scheme
-
EMC
AS/NZS CISPR32,RCM(Class A)
MEDIA PLAYER COMPATIBILITY
-
External Media Player Attachable
Yes (MP500 / MP700)
SOFTWARE COMPATIBILITY
-
Content Management Software
SuperSign CMS
-
Control and Monitoring Software
SuperSign Control / Control+
ACCESSORIES
-
Basic
Remote Controller, Power Cable, DP Cable, Manual, IR receiver, RS-232C Cable, LAN Cable, Guide Bracket, Screws
-
Optional
Wall mount (Landscape: WM-L640V, Portrait: WM-P640V)
White Paper
To access more technical documentation and resources, please visit the LG B2B partner portal.
