All Spec
PANEL
-
Screen Size
-
32"(80cm)
-
Panel Technology
-
IPS
-
Aspect Ratio
-
16 : 9
-
Native Resolution
-
1,920 x 1,080 (FHD)
-
Brightness*
-
400 cd/m2 (w/Glass 289 cd/m2)
-
Viewing Angle (H x V)
-
178 x 178
-
Response Time
-
10 ms (G to G BW), 7.1 ms (WOT)
-
Surface Treatment
-
Hard Coating (3H), Anti-glare Treatment of the Front Polariser (Haze Typ. 1%)
-
Life Time (Typ.)
-
50,000 hrs
-
Operation Hours
-
24 Hrs
-
Orientation
-
Portrait & Landscape
CONNECTIVITY
-
Input
-
HDMI (2), DP, DVI-D, RGB, Audio In, USB 3.0
-
Output
-
DP, Audio Out
-
External Control
-
RS232C In/out, RJ45 In, IR Receiver In, Pixer Sensor In
PHYSICAL SPECIFICATION
-
Bezel Colour
-
Black
-
Bezel Width
-
32.7 mm (Even)
-
Monitor Dimension (W x H x D)
-
768.4 x 462.9 x 74.5 mm
-
Weight (Head)
-
10.3 kg
-
Carton Dimensions (W x H x D)
-
852 x 560 x 152 mm
-
Packed Weight
-
12.2 kg
-
VESATM Standard Mount Interface
-
200 x 200 mm
SPECIAL FEATURES
-
SPECIAL FEATURES
-
Temperature Sensor, Auto Brightness Sensor, Tile Mode (Up to 15x15), Natural Mode @Tile Mode, ISM Method, DPM Select, Energy Saving, Smart Energy Saving, File Play with USB, PIP/PBP (2), Internal Memory 8GB (System 4GB + Available 4GB), Wi-Fi Built-in (802.11n combo), USB Cloning, Easy Brightness Control, IDB App. (Whiteboard App.), Fail Over, Mirroring, SoftAP, Beacon, Embedded Template, Built-in Speaker (10W+10W), Crestron ConnectedⓇ**
ENVIRONMENTAL CONDITIONS
-
Operation Temperature
-
0°C to 40°C
-
Operation Humidity
-
10% to 80%
POWER
-
Power Type
-
Built-In Power
-
Power Supply
-
100-240V~, 50/60Hz
-
Power Consumption-Typ. / Max.
-
60 W / 85 W
-
Power Consumption-Smart Energy Saving
-
45 W
STANDARD(CERTIFICATION)
-
Safety
-
AS/NZS 60950,CB Scheme
-
EMC
-
AS/NZS CISPR32,RCM(Class A)
-
ErP / Energy Star
-
N/A / Yes (Energy Star 7.0)
-
EPEAT (US Only)
-
N/A
MEDIA PLAYER COMPATIBILITY
-
OPS Type Compatible
-
Yes
-
External Media player Attachable
-
No
SOFTWARE COMPATIBILITY
-
Content Management Software
-
SuperSign CMS
-
Control and Monitoring Software
-
SuperSign Control/Control+
ACCESSORIES
-
Basic
-
Remote Controller (2ea Batteries Included), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, Memory Cover
-
Optional
-
Wall Bracket (LSW230B), OPS Kit (KT-OPSA)
TOUCH
-
Touch Type
-
IR (Scattering)
-
Scan Time
-
10 ms ↓
-
Interface
-
USB 2.0
-
Protection Glass Thickness
-
2.8T (Anti-glare)
-
Operating System Support
-
Windows 7, Windows 8/8.1/10, Mac OS X (10.7 or later), Android, Linux (kernel 3.9 or later)
-
Multi Touch Point
-
Max 10 Points
