All Spec
PANEL
-
Screen Size
84" (213cm)
-
Panel Technology
IPS
-
Aspect Ratio
16 : 9
-
Native Resolution
3,840 x 2,160 (UHD)
-
Brightness
350cd/m2 (Typ), 300cd/m2 with Protection Glass
-
Contrast Ratio
1,400:1
-
Dynamic CR
500,000:1
-
Viewing Angle(H x V)
178 x 178
-
Surface Treatment
Anti-glare Haze 10%
-
Life time
50,000 Hrs (Typ.)
-
Orientation
Landscape
CONNECTIVITY
-
Input
HDMI(2), DP(1), DVI-D(1)(w/o HDCP), Component AV(1), Audio(1), USB 3.0(1), USB 2.0(2)
-
Output
Audio(1), External Speaker(L/R)
-
External Control
RS232C(1), RJ45(1), IR/Light Sensor(1), Pentray Control(1)
PHYSICAL SPECIFICATION
-
Bezel Colour
Black
-
Bezel Width
34.0mm
-
Monitor Dimension (W x H x D)
1,951 x 1,137 x 112mm
-
Weight (Head)
104kg
-
Carton Dimensions (W x H x D)
2,050 x 1,261 x 330mm
-
Packed Weight
119.1kg
-
VESA TM Standard Mount Interface
600 x 400mm, M8
SPECIAL FEATURES
-
Additional
Temperature Sensor, Auto Brightness Sensor, Auto Power/Source Memory, Key Lock, DPM Select, File Play with USB, Internal Memory(8GB), Wi-Fi Dongle Ready
ENVIRONMENT CONDITIONS
-
Operation Temperature Range
0°C to 40°C
-
Operation Humidity Range
10% to 80%
POWER
-
Power Supply
100-240V~, 50/60Hz
-
Power Type
Built-In Power
-
Power Consumption (Typ. / Max.)
400W
-
Power Consumption (Smart Energy Saving)
30% ±5%
STANDARD(CERTIFICATION)
-
Safety
AS/NZS 60950, CB Scheme
-
EMC
AS/NZS CISPR 22, RCM (Class A)
-
Energy Rating
N/A
MEDIA PLAYER COMPATIBILITY
-
Slot PC compatible (optional)
Yes (MP500, MP700)
-
External Media Player Attachable
No
SOFTWARE COMPATIBILITY
-
SuperSign W/Lite
No
-
SuperSign C
Yes
-
Interactive White Board S/W
Yes
ACCESSORY
-
Accessory
Power Cord, Remote Controller(2ea batteries included), IR/Light Sensor Receiver, USB 2.0 Cable, HDMI 2.0 Cable, Display Port Cable, Cable Tie(2ea), Touch Pen(2ea), Pen Tray(1ea), Eye-Bolt Assy(2ea), Screw Package, ESG
-
Optional
Media Player : MP700/MP500, External Speaker : SP-2100, Pentray : KT-WT1(TBD)
