All Spec
PHYSICAL PARAMETERS
-
Pixel Configuration
-
3 in 1 SMD
-
Pixel Pitch (mm)
-
1.56
-
Screen Resolution
-
1,920 × 1,080
-
Module Dimensions (W x H, mm)
-
250 × 281.25
-
No. of Modules per Cabinet (WxH)
-
12 × 6 (Total 72)
-
Screen Dimensions (W × H × D, mm)
-
3,004.6 × 1,692.1 × 36.5 (Thickest 70)
-
Screen Surface Area (m²)
-
5.06
-
Screen Weight (kg)
-
129
-
Physical Pixel Density (pixels/m² )
-
409,600
-
Flatness of Cabinet (mm)
-
±0.2
-
Cabinet Material
-
Aluminum
-
Service Access
-
Front
OPTICAL SPECIFICATIONS
-
Brightness
-
500 nit
-
Colour Temperature
-
3,200 - 9,300
-
Visual Viewing Angle (H × V)
-
160 x 160
-
Brightness Uniformity
-
98%
-
Colour Uniformity
-
±0.015Cx,Cy
-
Contrast Ratio
-
3,000
-
Processing Depth (bit)
-
16
KEY FEATURES
-
Key Features
-
DPM, HDMI CEC, Auto Brightness, PIP/2PBP, On/Off Scheduling, Play via URL, Content Manager, SuperSign CMS , CestronConnected, HDR10/HDR10 Pro, SoftAP, ScreenShare(Miracast), Office Meeting Mode, One:Quick Share, LG ConnectedCare ,Height Adjustable Floor Stand (Sold separately).
ELECTRICAL SPECIFICATIONS
-
Power Consumption (W/Screen, Max.)
-
2,000
-
Power Consumption (W/Screen, Avg.)
-
800
-
Power Consumption(W/m²) Max
-
395
-
Power Consumption (BTU/h/Screen, Max.)
-
6,824
-
Power Consumption (BTU/h/Screen, Avg.)
-
2,730
-
Power Consumption (BTU/h/m², Max.)
-
1,348
-
Power Supply (V)
-
100 to 240
-
Frame Rate (Hz)
-
50 / 60
-
Refresh Rate (Hz)
-
≥2,880
OPERATION SPECIFICATIONS
-
Lifetime (Hours to Half Brightness)
-
100,000
-
Operating Temperature
-
0°C to +40°C
-
Operating Humidity
-
<90%RH (without condensation)
SPEAKER
-
Speaker
-
Built-in (9W + 9W)
CERTIFICATION
-
Certification
-
CE, FCC, ETL, CB
ENVIRONMENT
-
Environment
-
RoHS, REACH
CONTROLLER
-
Controller
-
Embedded LG WebOS Controller
CONNECTIVITY
-
Connectivity
-
HDMI(3), DP(1), USB, LAN, RS232C In/Out, IR, SPDIF
