All Spec
PHYSICAL PARAMETERS
-
Pixel Configuration
-
Micro LED
-
Pixel Pitch
-
0.94
-
Module Resolution(WxH)
-
160 x 180
-
Module Dimensions(WxH,mm)
-
150 x 168.8
-
Weight per Module(Kg)
-
145
-
No. of Modules per Unit Case(WxH)
-
4 x 2
-
Unit Case Resolution(WxH)
-
640 x 360
-
Unit Case Dimensions(WxHxD, mm)
-
600 x 337.5 x 44.9
-
Unit Case Surface Area(m²)
-
0.2025
-
Weight per Unit Case(kg/unit)
-
7
-
Weight per Square Meter(Kg/m²)
-
34.6
-
Physical Pixel Density(Pixels/m²)
-
1,137,778
-
Unit Case material
-
Die-cast Aluminum
-
Service Access
-
Front and Rear
OPTICAL SPECIFICATIONS
-
Min. Brightness(After Calibration)
-
Peak. 1,200nit ; Typ. 600nit
-
Colour Temperature
-
6,500K / 2,800~10,000K
-
Visual Viewing Angle(Horizontal)
-
160
-
Visual View Angel(Vertical)
-
140
-
Brightness Uniformity
-
95%
-
Colour Uniformity
-
±0.02Cx,Cy
-
Contrast Ratio
-
Peak. 100,000; Typ. 50,000:1
-
Processing Depth(bit)
-
20(HDR10, HDR10 Pro)
ELECTRICAL SPECIFICATIONS
-
Power Consumption(W/Unit, Max)
-
135
-
Power Consumption(W/Unit, Avg)
-
81
-
Power Consumption(W/m²) Max
-
667
-
Power Supply (V)
-
100 to 240
-
Frame Rate (Hz)
-
50/60
-
Refresh Rate (Hz)
-
3,840
OPERATION SPECIFICATION
-
Life time (Half Brightness)
-
100,000
-
Operating Temperature(℃)
-
0°C∘to +40°C
-
Operating Humidity
-
10-80%RH
-
IP Rating Front
-
IP50
-
IP Rating Rear
-
IP20
CERTIFICATION
-
Certification
-
Safety 60950-1, EMC Class B
ENVIRONMENT
-
Environment
-
RoHS
CONTROLLER
-
Input
-
HDMI(3), DP(1), USB(1)
-
Output
-
Ethernet(5Gx8), SPDIF(Audio, 5.1ch)
-
Control
-
IR(1), RS232C In(1)/Out(1), Ethernet(1)
-
Power
-
AC-100-240V-50/60HZ
-
Features
-
WebOS 4.1,Cisco Compatible,Creston Connected,SuperSign CMS, Signage 365, 16GB storage,Built-in Wi-FI
