All Spec
PHYSICAL PARAMETERS
-
Pixel Configuration
-
3 in 1 SMD
-
Pixel Pitch (mm)
-
6.00
-
Module Resolution (W x H)
-
32 x 32
-
Module Dimensions (W x H, mm)
-
192 x 192
-
Weight per Module (kg)
-
0.54
-
No. of Modules per Unit Case (W x H)
-
6 x 4
-
Unit Case Resolution (W x H)
-
192 x 128
-
Unit Case Dimensions (W x H x D, mm)
-
1,152 x 768 x 217
-
Unit Case Surface Area (㎡)
-
0.885
-
Weight per Unit Case (kg/unit)
-
42.0
-
Weight per Square Meter (kg/㎡)
-
47.5
-
Physical Pixel Density (pixels/㎡)
-
27,777
-
Flatness of Unit Case (mm)
-
± 1.0
-
Unit Case material
-
Aluminum
-
Service Access
-
Front or Rear
OPTICAL SPECIFICATIONS
-
Min. Brightness (After Calibration)
-
6,000
-
Color Temperature
-
3500-8500
-
Visual Viewing Angle (Horizontal)
-
160°
-
Visual Viewing Angle (Vertical)
-
135
-
Brightness Uniformity
-
≥97%
-
Colour Uniformity
-
±0.05Cx,Cy
-
Contrast Ratio
-
3,000
-
Processing Depth (bit)
-
16
ELECTRICAL SPECIFICATIONS
-
Power Consumption (W/Unit, Max.)
-
580
-
Power Consumption (W/Unit, Avg.)
-
232
-
Power Consumption (W/㎡, Max.)
-
656
-
Power Supply (V)
-
100 to 240
-
Frame Rate (Hz)
-
50 / 60
-
Refresh Rate (Hz)
-
4,000
OPERATION SPECIFICATIONS
-
Lifetime (Half brightness)*
-
100,000
-
Operating Temperature (°C)
-
-20 to +50
-
Operating Humidity
-
< 90%RH
CONTROLLER
-
Controller
-
LCLH001
