All Spec
PANEL
-
Screen Size (Inch)
-
55
-
Panel Technology
-
OLED
-
Back Light Type
-
OLED
-
Aspect Ratio
-
16:9
-
Native Resolution
-
1920 x 1080 (FHD)
-
Refresh Rate
-
120Hz
-
Brightness
-
150/400nit (APL 100%/25%)
-
Contrast Ratio
-
150,000:1
-
Dynamic CR
-
NO
-
Color Gamut
-
BT709 120%
-
Viewing Angle (H x V)
-
178º x 178º
-
Color Depth (Number of Colors)
-
1.07 Billion colors
-
Response Time
-
1ms (G to G), 8ms (MPRT)
-
Surface Treatment (Haze)
-
Haze 0%
-
Life time
-
30,000Hrs (Typ.)
-
Operation Hours (Hours/Day)
-
18/7 (Moving Content Only)
-
Portait / Landscape
-
YES / YES
-
Transparency
-
N/A
-
QWP (Quarter Wave Plate)
-
N/A
CONNECTIVITY
-
HDMI In
-
YES (1ea)
-
HDMI In (HDCP Ver.)
-
1.4
-
DP In
-
YES (HDCP 1.3)
-
DVI-D In
-
NO
-
RGB In
-
NO
-
Audio In
-
NO
-
RS232C In
-
YES
-
RJ45(LAN) In
-
YES (1ea)
-
IR In
-
YES
-
USB In
-
USB2.0 Type A (2ea)
-
HDMI Out
-
NO
-
DP Out
-
YES
-
Audio Out
-
YES
-
Touch USB
-
NO
-
External Speaker Out
-
NO
-
RS232C Out
-
YES
-
RJ45(LAN) Out
-
YES
-
IR Out
-
YES (Sharing RS232C Out)
-
Daisy Chain
-
Input : HDMI, DP / Output : DP
MECHANICAL SPECIFICATION
-
Bezel Color
-
Black
-
Bezel Width
-
Even Bezel : 0.9mm (Off Bezel) T/R/L/B : 5.3/5.3/5.3/11.0mm (On Bezel)
-
Weight (Head)
-
6.5Kg (Head) 3.4Kg (Signage Box)
-
Weight (Head+Stand)
-
N/A
-
Packed Weight
-
23.1Kg
-
Monitor Dimensions (W x H x D)
-
1220.3 x 696.8 x 4.9mm (Head) 782.8 x 238.4 x 34.7mm (Signage Box)
-
Monitor Dimension with Stand (W x H x D)
-
N/A
-
Carton Dimensions (W x H x D)
-
1345 x 804 x 207mm
-
Handle
-
NO
-
VESA Standard Mount Interface
-
N/A
FEATURE - HARDWARE
-
Internal Memory (eMMC)
-
16GB
-
Wi-Fi/BT (Built-in)
-
NO
-
Temperature Sensor
-
YES
-
Auto Brightness Sensor
-
NO
-
Pixel Sensor
-
NO
-
Proximity Sensor
-
NO
-
Current Sensor
-
NO
-
BLU Sensor
-
NO
-
Humidity Sensor
-
NO
-
Acceleration(Gyro) Sensor
-
NO
-
Power Indicator
-
NO
-
Local Key Operation
-
NO
-
FAN (Built-in)
-
NO
FEATURE - SOFTWARE
-
OS Ver. (webOS)
-
webOS 4.0
-
Local Contents Scheduling
-
YES
-
Group Manager
-
YES
-
USB Plug & Play
-
YES
-
Fail over
-
YES
-
Booting Logo Image
-
NO
-
No Signal Image
-
NO
-
RS232C Sync
-
YES
-
Local Network Sync
-
YES
-
Backlight Sync
-
NO
-
PIP
-
NO
-
PBP
-
NO
-
Screen Share
-
NO
-
Video Tag
-
YES (4 Video Tag)
-
Play via URL
-
NO
-
Screen Rotation
-
YES
-
External Input Rotation
-
YES
-
Gapless Playback
-
YES
-
Tile Mode Setting
-
YES
-
Setting Data Cloning
-
YES
-
SNMP
-
YES
-
ISM Method
-
YES
-
Auto Set ID
-
YES
-
Status Mailing
-
YES
-
Control Manager
-
YES
-
Cisco Certification
-
NO
-
Crestron Connected
-
YES
-
Smart Energy Saving
-
NO
-
PM mode
-
YES
-
Wake on LAN
-
YES
-
Network Ready
-
NO
-
Beacon
-
NO
-
HDMI-CEC
-
YES
-
SI Server Setting
-
YES
-
webRTC
-
NO
-
Pro:Idiom
-
YES
-
Brightness Compensation
-
NO
-
W/B Setting by Grey scale
-
NO
-
Scan Inversion
-
YES
ENVIRONMENT CONDITIONS
-
Operation Temperature
-
0 °C to 40 °C
-
Operation Humidity
-
10 % to 80 %
POWER
-
Power Supply
-
AC 100-240V~, 50/60Hz
-
Power Type
-
Built-in Power
POWER CONSUMPTION
-
Typ.
-
116W (IEC 62087)
-
Max.
-
318W
-
BTU (British Thermal Unit)
-
1054 BTU/Hr(Typ.), 1085 BTU/Hr(Max.)
-
Smart Energy Saving (70%)
-
N/A
-
DPM
-
0.5W
-
Power off
-
0.5W
SOUND
-
Speaker (Built-in)
-
NO
CERTIFICATION
-
Safety
-
CB / NRTL
-
EMC
-
FCC Class "A" / CE / KC
-
ERP / Energy Star
-
YES / NO
-
ePEAT(US only)
-
NO
OPS COMPATIBILITY
-
OPS Type compatible
-
N/A
-
OPS Power Built-in
-
N/A
SOFTWARE COMPATIBILITY
-
SuperSign CMS
-
YES
-
SuperSign Control+
-
YES
-
SuperSign WB
-
YES
-
SuperSign Cloud
-
NO
-
Promota
-
NO
-
Mobile CMS
-
YES
-
Connected Care
-
YES
LANGUAGE
-
OSD
-
English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arabic
ACCESSORY
-
Basic
-
Remote Controller(include battery 2ea), Power Cord, QSG, IR receiver, Regulation Book, Phone to RS232C Gender, FFC Cables(1600mmx4ea for connection between panel and Signage Box), DP Cable(2M), LAN Cable(1.5M), RS232 Cable(4P-4P,1.5M), LC Cable(VLC,3M), Wall Fixer(4ea), Wall Fixer Install Guide, Install Guide Sheet(2ea), Tape(10ea for Cabling / 2ea for Dust proof), Screw(M4xL25,10ea / M3xL5.5,8ea)
-
Optional
-
NO
SPECIAL FEATURE
-
Overlay Touch Compatibility
-
N/A
-
Smart Calibration
-
N/A
-
Tilt (Face up)
-
N/A
-
Tilt (Face down)
-
N/A
-
IP Rating
-
N/A
-
Conformal Coating (Power Board)
-
N/A
-
Power Protection
-
N/A
-
Direct Sunlight
-
N/A
