Capacity (Cooling)(Min/Rated Max)
6.4 / 14.2 / 16.2 kW
Capacity (Heating)(Min/Rated Max)
7.0 / 17.1 / 18.0 kW
Power Input (Cooling/Heating)
4.73 / 5.20 kW
EER
3.00
COP
3.29
Power Supply (V/ø/Hz)
220~240 / 1 / 50
Piping Connection (Liquid / Gas / Drain)
ø 9.52 mm / ø 15.88 mm / ø 32/25 mm
Air Flow Rate (High/Medium/Low)
60.0 / 50.0 / 40.0 m³/min - 1000/833/667 l/s
Sound Pressure (Cooling) (High/Medium/Low/Sleep)
46/45/44 dBA
Sound Pressure (Heating) (High/Medium/Low)
46/45/44 dBA
Sound Power (Cooling) (High)
(-) dBA
Dehumidification Rate
4.0 l/h
Dimensions (WxHxD)
1320 x 400 x 534 mm
Net Weight
48.0 kg (105.8)
Supply Air Spigot (WxH)
842 X 291 mm
Return Air Spigot (WxH)
1,152 X 317 mm
Fan Motor Output
195 X 2 W
External Static Pressure (Min~Max) Pa
60 - 200 (60 factory)
Compressor Type
Twin Rotary
Airflow Rate
55x2 m³/min (Rated) / 916x2 l/s
Sound Pressure (Cooling/Heating) (Rated)
54 dBA / 56 dBA
Sound Power (Cooling) (Max)
71 dBA
Dimensions (WxHxD)
950 x 1,380 x 330 mm
Net Weight
88 kg
Refrigerant (Type / Charge / Chargeless Piping Length [after 7.5m])
R410A / 3,300g / 40m
Operation Range (Cooling, Min - Max) / (Heating, Min - Max)
-10 ~ 48°C DB / -10 ~ 24°C WB
Power Supply (V/ø/Hz)
220~240 / 1 / 50
Running Current (Cooling/Heating) (Rated)
21.8/22.7A
Power Supply Cable (N x mm²)
3 x 6.0
Transmission Cable (N x mm²)
4 x0.75
Circuit Breaker
40 A
Piping Length Total
50 m
Piping Elevation Difference
30m
Piping Connection (Liquid / Gas) mm
ø 9.52 / ø 15.88
