Capacity (Cooling)(Min/Rated Max)
12.6 / 20.0 / 25.7 kW
Capacity (Heating)(Min/Rated Max)
14.1 / 22.4 / 30.0 kW
Power Input (Cooling/Heating)
3.5/6.47/10.78 / 4.0/6.59/10.80 kW
Running Current
10.6/10.7 A
Power Supply (V/ø/Hz)
230~240 / 1 / 50
EER
3.09
COP
3.4
Piping Connection (Liquid / Gas / Drain)
ø 9.52 mm / ø 22.2 mm / ø 32/25 mm
Air Flow Rate (High/Medium/Low)
70.0 / 65.0 / 60.0 m³/min - 1167/1084/1000 l/s
Sound Pressure (Cooling) (High/Medium/Low)
52/50/49 dBA
Sound Pressure (Heating) (High/Medium/Low)
52/50/49 dBA
Dehumidification Rate
3.67 l/h
Dimensions (WxHxD)
1,563 X 458 X 791 mm
Net Weight
97 kg
Supply Air Spigot (WxH)
1,044 X 286 mm
Return Air Spigot (WxH)
1,368 X 392 mm
Fan Motor Output
375 X 2 W
External Static Pressure (Min~Max) Pa
62-180(180 factory)
Compressor Type
Twin Rotary
Airflow Rate
190 m³/min (Rated) / 3167 l/s
Sound Pressure (Cooling/Heating) (Rated)
57 dBA / 57 dBA
Sound Power (Cooling) (Max)
78 dBA
Dimensions (WxHxD)
920 X 1,680 X 760 mm
Net Weight
181 kg
Refrigerant (Type / Charge / Chargeless Piping Length [after 7.5m])
R410A / 6,900g / 15m
Operation Range (Cooling, Min - Max) / (Heating, Min - Max)
-10 ~ 48°C DB / -15 ~ 24°C WB
Power Supply (V/ø/Hz)
380~415 / 3 / 50
Power Supply Cable (N x mm²)
5 x2.5
Transmission Cable (N x mm²)
2 x 1.0~1.5
Circuit Breaker
30 A
Piping Length Total
100 m
Piping Elevation Difference
30m
Piping Connection (Liquid / Gas) mm
ø 9.52 / ø 22.2
