CD (Manual / Software)
YES(Paper Manual)
D-Sub
No
DVI to VGA Gender
Yes
DVI-D
No
Easy Setup Guide
No
External Antenna (Wi-Fi)
Yes
External Calibrator
No
HDMI
No
HDMI to VGA Gender
No
Input Device
No
PC Audio
No
Power Adapter
Yes
Power Cord
Yes
RJ45 Gender
No
USB
No
VESA Bracket
Yes
Back Cover
Matt Black (Texture)
Front
Matt Black (Texture)
[ Key Location ]
Front
Key Description
Power
Key Number
1
Key Type
Tact
LED Color(On Mode)
White (PC Power / HDD)
LED Color(Power save mode)
LED OFF
Humidity Range
Operating : 20%~80%, Storage : 10%~90%
Temperature Range
Operating : 10°C ~ 40°C, Storage : -20°C ~ 60°C
Warranty
3 Years
Audio Input - [ Jack Location ]
Horizontal
Audio Input - Mic In
Yes
Audio Input - PC Audio In
No
Audio Output - [ Jack Location ]
Horizontal
Audio Output - Headphone Out
Yes
Audio Output - Line-out
No
Audio Output - Optical out
No
Audio Output - RCA
No
DC-In
Yes
Networking - BT
BT4.0
Networking - Fiber
No
Networking - LAN
1 x RJ45 : Ehternet 10/100/1000 (Support Wake on LAN)
Networking - LTE Communication
No
Networking - Wireless
Intel Dual Band Wireless-AC 3168 1x1 AC (AGN support, BT 4.0 + LE Combo), Extermal Antenna (Dipole)
Signal Input - [ Jack Location ]
Horizontal
Signal Input - DC-in
Yes
Signal Input - DisplayPort
No
Signal Input - D-Sub
No
Signal Input - DVI
No
Signal Input - HDMI
No
Signal Input - mini DisplayPort
No
Signal Input - Thunderbolt (Ver)
No
Signal Output - DisplayPort Out
Yes(1.2)
Signal Output - DVI out
Yes
Signal Output - HDMI Out
Yes
USB
4 x USB2.0, 2 x USB3.0
Certifications (Based on US ratings)
No
Display Support
4096x2160@50Hz, 3840x2160@60Hz (via DisplayPort 1.2 out), 4096x2160@24Hz, 3840x2160@30Hz, 2560x1440@60Hz (via HDMI1.4 out), 1600x1200@60Hz (via DVI out)
Expansion Slot
M.2 Slots x 2 (Slot 1 : 32GB SSD, Slot 2 : WiFi + Bluetooth card) * Note: Slot 1 should be capable of supporting both SATA and PCIe NVMe SSDs. SO-DIMM x 1 (Slot 1 : 4GB DDR4)
Graphics
Integrated Graphics
Management Console
No
ODD
No
Operation System
Non OS
Processor
AMD Pairie Falcon GX-212JJ
S/W (Pre-Installed App)
No
Storage
32GB (M.2 SSD), M.2 2280/2242 SSD Supported (SATA/PCIe supported)
System Memory
4GB DDR4
TPM (Trust Platform Module)
Software TPM
Consumption - DC Off(Max)
0.6Watt
Consumption - Long Idle(Display OFF)
6.0Watt
Consumption - Short Idle(Display ON)
10Watt
Consumption - Sleep Mode(Max)
1.0Watt
Consumption - TEC (kWh)
41.4 kWh
Input
100~240V (50/60Hz)
Output
48 Watt
Type
Adapter
Kenshinton Lock Slot
Yes
Dimension (WxDxH) - Box (mm)
231mm x 81mm x 179mm
Dimension (WxDxH) - Set (without Stand, mm)
180mm x 39.9mm x 117mm
Dimension (WxDxH) - VESA / Wall Mount (mm)
100 x 100, 75 x 75 (wall mount)
Stuffing - Pallet(20ft/40ft/40ft HC)
2,500/5,250/-(Air), 3,000/6,300/-(Vessel)
Weight - Box (Kg)
1.85kg
Weight - Set (without Stand, Kg)
1kg
Audio Output (Watt)
No
Type
No
General Function - DDC/CI
No
General Function - HDCP
No
General Function - Intelligent Auto (Auto Adjustment)
No
General Function - Key Lock
No
General Function - Plug & Play
No
General Function - Remote Control
No
General Function - Response Time Control
No
General Function - sRGB
No
PC Features - Etc.
No
PC Features - SD Card Slot
No
PC Features - Webcam
No
Picture - PBP / PIP
No
Picture - Picture Mode
No
Picture - Ratio
No
Picture - Reader Mode
No
Sound - Maxx Audio
No
Special Feature - Color Calibrated
No
Special Feature - Dual Control
No
Special Feature - Dual Smart Solution (Dual web, Dual Display, Smart Resolution )
No
Special Feature - Flicker safe
No
Special Feature - Motion Energy Saver
No
Special Feature - Off Timer
No
Special Feature - OSC (On Screen Control / Screen Split)
No
Special Feature - Power Charge
No
Special Feature - SIX Axis Control
No
Special Feature - Smart Energy Saving
No
Special Feature - Super Resolution+
No
Special Feature - Touch
No
Special Feature - True Color Pro / Finder
No
Bluetooth
No
CB
Yes
CE
Yes
DisplayPort
No
EPA
No
EPEAT
No
FCC-B
Yes
IEC60601
No
ISO 9241-307
No
PVC-Free
No
ROHS, REACH
ROHS, REACH
TCO (Ver.)
No
TUV-Ergo
Yes
TUV-GS
Yes
TUV-type
Yes
UL(cUL)
Yes
Wi-Fi
No
Windows
No
Box Printing Type
Flexo
Handle
No
Packing Material
A-Flute
Stacking Type
Vertical
Stand Packing Type
No
