Panel Size
32”Class(31.51” measured diagonally)
Panel Technology
Direct LED
Native Resolution
1366 x 768 (HD)
Frame Rate
60Hz
Response Time
9ms
Brightness (cd/m2)
240 cd/m²
Viewing Angle (HxV)
178° x 178°
Contrast Ratio Static (Typ)
1,200:1
Dynamic Contrast Ratio
1,000,000:1
Analog
Yes (NTSC)
Digital
Yes (ATSC / QAM/VSB)
Audio Output
10W + 10W
Clear Voice II
Yes
Sound Mode
Yes (6 Modes: Standard, News, Music, Cinema, Sport, Game)
Speaker System
2.0 ch
Optical Sound Sync
Yes
Sound Optimizer
Yes (3 Modes: Normal, Wall-Mount Type, Stand Type)
HDMI In
2 Side
USB (2.0)
1 Side
RF In
1 Rear
AV In
1 Rear
Digital Audio Out
1 Rear (Optical)
HDMI/HDCP Input
1 Rear
RGB In (D-sub 15pin) - PC
1 Rear
PC Audio Input
1 Rear (Sharing with AV In)
LAN Port
1 Rear
RJ45(RJP interface)
1 Rear
TV link Configuration(phone jack type)
1 Rear
External Speaker Out
1 Rear (3.5mm phone jack)
PTC Configuration (phone jack type)
1 Rear
MPI Jack (RJ-12)
1 Rear
Bezel Width (L/R/U/B) on (mm)
12mm/11.6mm/ 16.6mm
Bezel Width (L/R/U/B) off (mm)
10.5mm/10.0mm /14.0mm
With Stand
28.8” x 19.0” x 11.1”
Weight
19.6 lbs
Without Stand
28.8” x 17.0” x 2.2”
Weight (Without Stand)
13.2 lbs
Carton
32.1” x 20.1” x 7.5”
Weight (Carton)
23.6 lbs
VESA™ Standard Mount Interface
200mm x 200mm
Swivel
Yes (± 20), with Lock Down plate (±20/45/90°)
Colour
Metallic Titan
Applications (Pro:Centric Smart)
Yes (PCA3.0)
Auto Configuration
Yes (EzManager)
b-LAN
Yes
HDMI-CEC
Yes
HTNG-CEC
Yes
Remote Diagnosis
Yes (Self Diagnosis)
Welcome Screen (Splash Image)
Yes
Commercial Grade Stand
Yes
Lock Mode
Yes
HCAP (GEM/Flash)
Yes
Audio Codec
AC3(Dolby Digital), EAC3, AAC, Mpeg, MP3, PCM
Multicast/Unicast ready
Yes (Pro:Centric Server)
Smart Energy Saving (Auto Power Off)
Yes
Motion eye care (intelligent sensor)
Yes
RF(1/2Tuner)
Yes (1 Tuner)
MHL
Yes
Pro:Centric
Yes (V)
Pro:Idiom
Yes
SI Compatible (TVLink Protocol)
Yes (MPI protocol)
Hotel Mode / PDM / Installer Menu
Yes (Installer Menu)
Multi IR Code
Yes
IR Out
Yes (MPI Jack)
Auto Off / Auto Sleep
Yes
RJP Compatibility
LG,Teleadapt (RJ45, HDMI CEC), G-Link(HDMI-CEC)
RJP Interface
Yes (RJ45, HDMI)
Kensington Lock
Yes
External Speaker Out
Yes (Variable/Fixed/Line Out, 3.5mm, Stereo, Single ended Type(GRD,L+,R+), 1W with 8Ω)
USB
Yes (USB 2.0)
USB Cloning
Yes
Moving Picture Playback (SD/HD/Plus HD)
Divx HD
JPEG
Video Mute
Yes
Credenza/Security Screw Hole
Yes
One Channel Map/Logical Channel Map
Yes (LCM)
Lock Down Plate (for easy installing)
Yes (for easy installing )
Dynamic Colour Enhancer
Yes
Triple XD Engine
Yes
Real Cinema 24p (3:3 pull down)
Yes
Aspect Ratio
Yes (5 Modes: 16:9, Just scan, Set by program, 4:3, Zoom)
Stand-by
0.5W↓
Watts (typical)
23W
Power Source
110 ~ 240V, 50/60Hz
REMOTE JACK PANEL COMPATIBILITY (RJP)
G-Link, teleadapt, LG
UPC Code
719192 915985
Warranty
2-Year Limited Warranty (Parts/Labor)
