Bottom Freezer Refrigerator with Swing Freezer Door (22.4 cu.ft.)

Specs

Reviews

Support

Bottom Freezer Refrigerator with Swing Freezer Door (22.4 cu.ft.)

LBN22517ST

Bottom Freezer Refrigerator with Swing Freezer Door (22.4 cu.ft.)

()
Print

All Spec

GENERAL

  • Capacity

    22.4 cu.ft.

FEATURE

  • Freezer Door Type

    Swing

  • MultiAir Flow System

    Yes

  • Digital Temperature Controls

    Internal Thumbwheels

  • Door Alarm

    Yes

  • LoDecibel Operation

    Yes

REFRIGERATOR

  • No. of Shelves

    1 Full / 2 Split

  • Shelf Style

    3 Fixed

  • Cantilevered Shelves

    Yes

  • Shelf Construction

    Tempered Glass

  • Bins

    2 Humidity Crisper

  • Refrigerator Light

    Reveal (2x40W)

REFRIGERATOR DOOR

  • No. of Door Bin

    3

  • Door Bin Material

    1 Piece Opaque

FREEZER

  • Upper Drawer

    Wire

  • Lower Drawer

    Wire

  • Ice Maker

    Not Ready

  • Freezer Door Bin

    Yes

  • Freezer Light

    40W

MATERIAL AND FINISHES

  • Foam Door Insulation

    Cyclo Pentane (No CFC, No HCFC)

  • Door Style

    Contour

  • Bio Shield AntI Bacterial Door Shield

    Yes

  • Toe Grille

    Yes

  • Back

    Flush & Metal cover over mechanical parts

  • Handles

    Matching Commercial Handles

  • Color

    Stainless Steel

  • Cabinet Color

    Grey

  • Reversible Door

    Yes

DIMENSIONS AND WEIGHT

  • Depth w/ Handles

    34 1/2"

  • Depth w/o Handles

    32"

  • Depth w/o Door

    28 1/4"

  • Depth (Total with Door Open)

    62"

  • Height to Top of Case

    67 11/16"

  • Height to Top of Door Hinge

    68 3/8"

  • Width

    32 3/4"

  • Width (door open 90 deg. w/o handle)

    34 1/8"

  • Installation Clearance

    Sides 1/8" x Top 1" x Back 2"

  • Carton Dimensions (WxHxD)

    35 1/8" x 72 1/2" x 36"

  • Weight (lbs): Unit/Carton

    237/263

UPC CODE

  • UPC Code

    772454050251

WARRANTY

  • Warranty

    1 Year parts and Labour, 7 Years on the Sealed System
