SUMMARY
DIMENSIONS
![LRYKS3106S](/content/dam/channel/wcms/ca_en/images/spec/LRYKS3106S-M.jpg)
All Spec
CAPACITY
-
Refrigerator (cu.ft.)
-
20.4 cu. ft.
-
Refrigerator (cu.ft.)
-
16.9
-
Freezer (cu.ft.)
-
10.3 cu. ft.
-
Freezer (cu.ft.)
-
8.6
-
Total Capacity (cu.ft.)
-
30.7 cu. ft.
-
Total Capacity (cu.ft.)
-
31
ENERGY
-
Energy Consumption (kWh/year)
-
699
-
ENERGY STAR® Qualified
-
Yes
ICE SYSTEM
-
Dispenser Type
-
Integrated Tall Ice & Water Dispenser
-
System Type
-
Slim SpacePlus®
-
Daily Ice Production
-
3.0 lbs / 3.3 (Ice Plus) 0.7 lbs (Clear big ice) 1.5 lbs (Cubed mini ice)
-
Craft Ice™ Daily Ice Production
-
6/3
-
Ice Storage Capacity
-
3.0 + 3.8 + 4.0 lbs
-
Cube & Crushed Ice
-
Yes
-
IcePlus™
-
Yes
-
Dual Ice with Craft Ice™
-
Yes
-
Water Filter
-
LT1000P
-
UVNano™
-
Yes
COOLING
-
Multi Air Flow Cooling:
-
Yes
-
Temperature Sensors
-
3
-
Compressor Type
-
Smart Inverter
-
Refrigerant [Name / Amount(g)]
-
Low GWP, Zero ODP and More Energy Efficient Refrigerant (R600a / 57g)
-
Refrigerant [Name / Amount(oz)]
-
Low GWP, Zero ODP and More Energy Efficient Refrigerant (R600a / 2.01oz)
-
Fresh Air Filter
-
Yes
DISPLAY & ETC.
-
Display Type
-
Smooth Touch Control / White LED
-
Temperature Controls
-
Electronic/Digital
-
Door Alarm
-
Yes (Default)
-
Child Lock
-
Yes
-
Decibel™ Quiet Operation
-
Yes
-
Smart Diagnosis
-
Yes
-
Auto Closing Door Hinge
-
Yes
-
wi-fi Enabled
-
Yes
-
ThinQ®
-
Yes
-
Special Features
-
Door Cooling+
-
Sabbath
-
Yes
REFRIGERATOR
-
Door-in-Door®
-
Yes
-
No. of Shelves
-
4 Split(3 Fixed+1Folding)
-
Folding Shelf
-
1
-
Cantilevered Shelves
-
Hybrid Cantilevered
-
Shelf Construction
-
SpillProof™ Tempered Glass
-
Crisper Bins
-
2 Crispers
-
Glide N’ Serve™ Drawer
-
Yes
-
CoolGuard™
-
Yes
-
Handle Type
-
Bar
-
No. of Door Bins
-
8 Total (2 Adjustable Gallon Sized)
-
Door Bin Construction
-
1 Piece (Clear)
FREEZER
-
Door Type
-
Pull Drawer
-
Drawers/Shelves
-
3-Tier Organization
-
DuraBase™ Solid Drawer Base
-
Yes
-
Freezer Light Upper
-
LED Lighting
-
Freezer Handle
-
SmartPull™ Handle
MATERIALS & FINISHES
-
Flat type Door
-
Yes
-
Hidden Hinges
-
Yes
-
Surface
-
Smooth
-
Handles
-
Matching Commercial Handles
-
Smudge Resistant Finish
-
Yes
-
Insulation
-
Low GWP and Zero ODP Blowing Agent
DIMENSIONS
-
Width
-
35 3/4"
-
Height to Top of Hinge
-
70 1/4"
-
Depth with Handles
-
31 5/8"
-
Depth (with handles)
-
34 1/4"
-
Width (Door Open 90˚ without Handle)
-
40"
-
Width (Door Open 90˚ with Handle)
-
44 7/8"
-
Door Edge Clearance with Handle
-
4 1/4"
-
Door Edge Clearance without Handle
-
2 1/4"
-
Height to Top of Case
-
68 7/8"
-
Depth without Door
-
29 7/8"
-
Depth without Door
-
24 7/8"
-
Depth without Handles
-
34 1/4"
-
Depth without Handles
-
29 1/4"
-
Depth (Total with Door Open)
-
48 3/4"
-
Depth (Total with Door Open)
-
43 1/2"
-
Depth (Draw Open Fully without Handle)
-
48 7/8"
-
Installation Clearance
-
Sides 1/8", Top 1", Back 2"
-
Weight (Unit/Carton)
-
317 lbs. / 339 lbs.
-
Weight (Unit/Carton)
-
322 lbs / 352 lbs
-
Carton Dimensions (WxHxD)
-
38" x 73" x 32"
-
Carton dimensions (W x H x D)
-
38" x 72" x 37"
LIMITED WARRANTY
-
Parts & Labour
-
1 Year
-
Sealed System (Parts only)
-
7 Years
-
Compressor (Parts Only)
-
10 Years
UPC
-
UPC
-
195174034811
