LG SUPER UHD TV

Specs

Reviews

Support

LG SUPER UHD TV

86UH9500

LG SUPER UHD TV

(0)
86UH9500
Print

All Spec

DISPLAY MODULE

  • Display Type

    LED

  • Screen Size

    86”

  • Resolution

    3840 x 2160

  • Backlight

    Edge

  • Refresh Rate

    240 Hz

  • 3D

    Yes

  • Viewing Angle

    Wide viewing angle

  • Dimming

    Local Dimming

BROADCAST SYSTEM

  • Analog TV Reception

    Yes (NTSC)

  • Digital TV Reception (Terrestrial,Cable)

    Yes

VIDEO

  • Picture Engine

    Prime Mastering Engine

  • Ultra Luminance

    Yes

  • ColourPrime

    ColourPrime Plus

  • 3D Colour Mapping

    Yes

  • Illuminance Sensor

    White Sensor

  • Colour Depth

    Billion Rich Colours

  • 4K Upscaler

    Yes

  • Dynamic Scanning

    No

  • Smart Content Optimizer

    Yes

  • Contrast Maximizer

    Yes

  • Dolby Vision

    Yes

AUDIO

  • Audio Output / Speaker System

    80W / 5.2ch

  • Dolby Digital Decoder

    Yes

  • DTS Decoder

    Yes DTS M6

  • Mono / Stereo / Dual (MTS/SAP)

    Yes

  • Surround Mode

    Ultra Surround

  • harman/kardon Sound

    Yes

  • Magic Sound Tuning

    Yes

  • Smart Sound Mode

    Yes

  • Clear Voice

    Clear Voice III

  • Hi-Fi Audio

    Yes

  • TV Installation Type

    Magic Sound Tuning

  • Wireless Sound Sync / Private Sound Sync

    Yes

  • Audio Codec

    AC3(Dolby Digital), EAC3, HE-AAC, AAC, MP2, MP3, PCM, DTS, DTS-HD, DTS Express, WMA

HARDWARE PLATFORM

  • CPU

    Quad

  • HEVC Decoder

    4K@60fps,10bit

  • VP9 Decoder

    4K@60fps, 8bit

  • Wi-Fi

    802.11.ac

  • Bluetooth

    Yes

MAIN FEATURES

  • Magic Zoom

    Yes

  • Magic Mobile Connection

    Yes

  • STB Control

    Yes

  • My Content

    Yes

  • My Channels

    Yes

  • My Starter

    Yes

  • Channel Advisor

    Yes

  • Multi-view

    Yes

  • LG Content Store

    Yes

  • IoTV

    Yes

  • Web Browser

    Yes

SMART SHARE

  • Mobile App(LG TV Plus)

    Yes

  • Mobile TV On

    Yes

  • WiDi

    Yes

  • Miracast

    Yes

  • Content Sharing

    Yes

  • webOS 3.0

    Yes

OTHER

  • Natural Voice Recognition

    Yes

  • Speech To Text

    Yes

  • Simplink (HDMI CEC)

    Yes

  • External Device App Download for USB

    Yes

  • Simultaneous Audio

    No

  • Block access to harmful site

    Yes

  • OSD Language

    4 Languages

AV INPUTS/OUTPUTS

  • HDMI 6G : 422 / HDR Support 3G : 420

    3 (6G) Side

  • USB

    3 (3.0 : 1 / 2.0 : 2) Side

  • RF

    1 Rear

  • Composite in (CVBS+ Audio)

    1(Gender) Rear

  • Component In (Y,Pb,Pr + Audio)

    1(Gender) Rear

  • Digital Audio Out (Optical)

    1 Rear

  • LAN

    1 Rear

  • RS-232C (Control / SVC)

    1 (Phone Jack Type) Rear

  • Headphone Out / Line Out

    No

ACCESSORIES

  • # of 3D Glasses (Model Number)

    2EA

  • Remote Controller

    MR15R

  • Component / AV Gender

    AV gender 1 / Comp gender 1

  • Power Cable

    Yes

  • Owner's Manual

    Yes

  • Magic Remote

    Yes

POWER

  • ENERGY STAR® Qualified

    No

  • Power Supply (Voltage, Hz)

    120V, 50/60Hz

  • Power Consumption

    TBD

  • Standby Mode

    0.5W

DIMENSIONS / ETC.

  • TV without Stand (W x H x D)

    1938 x 1114 x 67.4mm | 76.3” x 43.86” x 2.65”

  • TV with Stand (W x H x D)

    1938 x 1176 x 366mm | 76.3” x 46.3” x 14.41”

  • Shipping Dimensions (W x H x D)

    2108 x 1263 x 285mm | 82.99” x 49.72” x 11.22”

  • TV without Stand Weight

    50.3 kg, 110.79 lbs

  • TV with Stand Weight

    54.6 kg, 120.26 lbs

  • Shipping Weight

    69.5 kg, 153.08 lbs

  • VESA Size

    600 x 400

  • UPC

    719192603677

WARRANTY

  • Limited Warranty

    1 Year Parts & Labour

  • Model Year

    2016
