Alle Spezifikationen
BETRIEBSSTROM
-
#1
-
50 Hz(Гц) 380-415 V(B) 3N~
KÜHLLEISTUNG
-
Nennleistung (kW)
-
22.4
HEIZLEISTUNG
-
Nennleistung (kW)
-
24.5
LEISTUNGSAUFNAHME(HEIZEN)
-
Nennleistung (kW)
-
8.45
LEISTUNGSAUFNAHME(KÜHLEN)
-
Nennleistung (kW)
-
6.96
EFFIZIENZ
-
EER(Nennwert) (W/W)
-
2.65
-
COP(Nennwert) (W/W)
-
3.52
-
SEER (Wh/Wh)
-
7.13
-
SCOP (Wh/Wh)
-
4.53
-
Pdesign(@-10℃, Heizen) (kW)
-
14.9
LÜFTER
-
Typ
-
Axial Flow fan
-
Luftvolumenstrom (Hoch) (m³/min x No.)
-
140
-
Entladungsrichtung(seitlich /oben)
-
Side
LÜFTERMOTOR
-
Antrieb
-
DC Inverter
-
Leistung (W x No.)
-
124x2
KOMPRESSOR
-
Typ
-
Hermetically Sealed Scroll
-
Hubvolumen (cm³/rev)
-
43.8
-
Motorleistung (W x No.)
-
4200x1
-
Startverfahren
-
DC Inverter
-
Öltyp
-
FW68D(PVE)
WÄRMETAUSCHER
-
Typ
-
Wide Louver Plus
ABMESSUNGEN
-
Netto(B x H x T) (mm)
-
950 x 1380 x 330
-
Transport(B x H x T) (mm)
-
1140 x 1553 x 466
GEWICHT
-
Netto (kg)
-
115
-
Transport (kg)
-
127
ÄUSSERES
-
Farbe
-
Warm Gray
-
RAL (klassisch)
-
RAL 7044
KÄLTEMITTEL
-
Typ
-
R410A
-
Werksfüllung (kg)
-
3.5
-
GWP(Global Warming Potential)
-
2087.5
-
t-CO₂ Äquivalent
-
7.306
-
Kontrollart
-
Electronic Expansion Valve
ROHRLEITUNGSANSCHLÜSSE
-
Flüssig (mm(inch))
-
Φ9.52 (3/8)
-
Gas (mm(inch))
-
Φ19.05 (3/4)
SCHALLDRUCKPEGEL(AUSSENEINHEIT)
-
Kühlen / Heizen (dB(A))
-
57/57
SCHALLLEISTUNGSPEGEL(AUSSENEINHEIT)
-
Kühlen / Heizen (dB(A))
-
78/81
VERBINDUNGSKABEL
-
Datenleitung(VCTF-SB) (mm² × cores)
-
1.0 ~ 1.5 × 2C
ANZAHL DER ANSCHLIESSBAREN INNENEINHEITEN
-
Max. (EA)
-
13
