SM3B Series

Key Features

Choose your Size

component-OBScountrySelectDesc

SM3B Series
PANEL
  • Screen Size
    43"
    Resolution
    1,920 x 1,080 (FHD)
  • Brightness
    350cd/m²
CONNECTIVITY - INTPUT
  • HDMI
    Yes (1), HDMI /HDCP2.2
    DP
    Yes (1), DP /HDCP1.3
  • DVI-D
    Yes (1), HDCP2.2
    Analog (RGB)
    Yes (1)
  • Audio In
    Yes (1), RGB/DVI
    External Control (RS232C IN)
    Yes (1)
  • External Control (RJ45)
    Yes (1)
    External Control (IR receiver)
    Yes (1)
  • External Control (Pixel Sensor)
    Yes (1)
    USB (USB3.0)
    Yes (1)
  • SD Card (SDHC/Full Size)
    Yes (1)
CONNECTIVITY - OUTPUT
  • DP Out
    Yes (1), SST/DP1.2a
    Audio Out
    Yes (1)
  • Externel Speaker Out
    Yes (L/R), 6 ohm
    External Control (RS232C OUT)
    Yes (1)
PHYSICAL SPECIFICATION
  • Bezel Width
    11.9mm (T/R/L), 18mm (B)
    Monitor Dimension (W x H x D)
    969.6mm X 563.9mm X 38.6mm
  • Weight (Head)
    9.8kg
    VESA™ Standard Mount Interface
    200mm x 200mm
MEDIA PLAYER COMPATIBILITY
  • OPS type compatible
    Yes
    External Media player Attatchable
    Yes (MP500/MP700)
SOFTWARE COMPATIBILITY
  • SuperSign-w lite
    Yes
    SuperSign-c
    Yes
ACCESSORY
  • Basic
    Remote Controller (include battery 2ea), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, Memory cover
    Optional
    Speaker (SP-5000), Stand (ST-432T), Pixel sensor (KT-SP0), Media player, Wall bracket (LSW230B), VESA Adapter (AM-B220S), OPS Kit (KT-OPSA), HD Base T (EB-B100)
GENERAL
  • Region
    Global
