Min ~ Rated (T1) ~ Max - kW
3.36 ~ 8.20
~ 9.96
Min ~ Rated (T1) ~ Max - Btu/h
11,480 ~ 28,000
~ 34,000
Rated (T3) - kW
7.05
Rated (T3) - Btu/h
24000
Min ~ Rated ~ Max - kW
3.28 ~ 8.75
~ 9.09
Min ~ Rated ~ Max - Btu/h
11,200 ~ 30,000
~ 31,000
Cooling (Rated, T1) - kW
2.26
Cooling (Rated, T3) - kW
2.47
Heating (Rated) - kW
2.50
EER (T1) - Btu/h W
12.40
EER (T3) - Btu/h W
9.70
COP (H1) - W/W
3.50
V, Φ, Hz
230, 1, 50
Type
Axial Fan
Type
BLDC
Type
Twin Rotary
Net (W x H x D)-mm
950 x 834 x 330
Net-kg
61.0
Color
Warm Gray
Type
R410A
Precharged Amount - kg
2.2
Liquid-mm(inch)
Φ9.52 (3/8)
Gas-mm(inch)
Φ15.88 (5/8)
IDU - ODU (Min / Max)-m
5 / 50
IDU - ODU (Max)-m
30
Cooling-dB(A)
51
Heating-dB(A)
53
Power Supply Cable (H07RN-F)-mm² x cores
2.5 x 3
Cooling-℃(DB)
0 ~ 54
Heating-℃(WB)
-5 ~ 18
V, Φ, Hz
230, 1, 50
Type
Sirocco
Air Flow Rate (H / M / L)-㎥/min
32.0 / 28.0 / 24.0
External Static Pressure-mmAq
8
Type
BLDC
Net (W x H x D)-mm
1,250 x 270 x 700
Net-kg
32.0
Protection Device
Fuse
O.D / I.D-mm
32 / 25
Cooling (H / M / L)-dB(A)
36.0 / 34.0 / 33.0
Heating (H / M / L)-dB(A)
36.0 / 34.0 / 33.0
Power and Communication Cable (H07RN-F)-mm² x cores
0.75 x 4
