Key Features
Cooling Capacity(Min ~ Rated ~ Max)
0.88 ~ 3.34 ~ 3.87 kW3,000 ~ 11,413 ~ 13,200 Btu/h
Power Input - Cooling(Min ~ Rated ~ Max)
140 ~ 1,090 ~ 1,350 W
Running Current - Cooling(Min ~ Rated ~ Max)
0.80 ~ 6.00 ~ 7.20 A
EER
4.35 W/W14.85 (Btu/h)/W
Energy Label Grade - Cooling/Heating
A+
Power Supply
1, 220, 50
Available Voltage Range
187 ~ 276 V
Power Factor - Cooling / Heating
80% / No
Moisture Removal
0.6ℓ/h
Indoor - Air Flow Rate(Cooling, Max/H/M/L)
12,5/No/No
Indoor - Sound Pressure Level(Cooling, H / M / L / SL)
42 / 36 / 28 / 21 dB(A)
Indoor - Dimensions (W × H × D) - Net
837 × 302 × 189 mm
Indoor - Dimensions (W × H × D) - Shipping
905 × 383 × 261 mm
Indoor - Weight (Net)
8.9 kg
Indoor - Weight (Shipping)
10.6 kg
Air Flow Rate - Outdoor,Max
27 m³/min
Outdoor - Dimensions (W × H × D) - Net
717 × 483 × 230 mm
Outdoor - Dimensions (W × H × D) - Shipping
836 × 321 × 540 mm
Outdoor - Weight(Net)
25.2 kg
Outdoor - Exterior Color Code
Munsell 7.5BG 10/2
Circuit Breaker
15A
Power Supply Cable
3 x 1.0 No. x mm²
Power Supply to Unit
Outdoor
Piping - Size - Liquid / Gas
Ø 6.35 / Ø 9.52 mm
Piping - Connections Method - Indoor / Outdoor
Flared / Flared
Drain Hose Size - O.D, I.D
21.5, 16.0 mm
Between Indoor & Outdoor - Piping Length(Min / Standard / Max)
3 / 7,5 / 15 m
Between Indoor & Outdoor - Max. Elevation Difference
7 m
Refrigerant - Type
R410A
Pre Charge
850g
Additional Charge
20g/m
Compressor (Type)
Twin Rotary
