Summary
All Spec
GENERAL SPECIFICATION
-
Cooling Capacity (Min ~ Rated ~ Max)
-
1.03 ~ 6.45 ~ 7.18 KW
3,500 ~ 22,000 ~ 24,500 Btu/h
-
Power Input - Cooling (Min ~ Rated ~ Max)
-
240 ~ 1,980 ~ 2,400 W
-
Running Current - Cooling (Min ~ Rated ~ Max)
-
1.40 ~ 9.40 ~ 10.5 A
-
EER
-
11.11 (Btu/h)/W
3.26 W/W
-
Energy Label Grade - Cooling
-
A++++
-
Available Voltage Range
-
187 ~ 253 V
-
Power Supply
-
1, 220, 50 (Φ/V/Hz)
-
Power Factor - Cooling
-
96%
-
Indoor - Air Flow Rate (Cooling, Max/H/M/L)
-
20/15/13.5/10.5 m³/min
-
Indoor - Sound Pressure Level (Cooling, H/M/L/SL)
-
53/47/42/34/31 dB(A)
-
Indoor - Dimensions (W × H × D) - Net
-
998 × 345 × 210 mm
-
Indoor - Dimensions (W × H × D) - Shipping
-
1053 × 424 × 278 mm
-
Indoor - Weight (Net)
-
12.2 kg
-
Indoor - Weight (Shipping)
-
14.4 kg
-
Outdoor - Sound Pressure Level (Cooling, Rated)
-
55 dB(A)
-
Outdoor - Dimensions (W × H × D) - Net
-
870 × 650 × 330 mm
-
Outdoor - Dimensions (W × H × D) - Shipping
-
1045 × 710 × 458 mm
-
Outdoor - Weight (Net)
-
42.0 kg
-
Outdoor - Weight (Shipping)
-
49.0 kg
-
Compressor - Type
-
Twin Rotary
-
Compressor - Motor Type
-
BLDC
-
Fan (Indoor) - Type
-
Cross Flow Fan
-
Fan (Indoor) - Motor Output
-
58 W
-
Fan (Outdoor) - Type
-
Propeller Fan
-
Fan (Outdoor) - Motor Output
-
70 W
-
Heat Exchanger - Condenser (Material, Tube/Fin)
-
Cupper
-
Heat Exchanger - Condenser (Corrosion Protection)
-
Gold
-
Circuit Breaker
-
20 A
-
Power Supply to Unit
-
Outdoor
-
Piping - Size (Liquid)
-
1/4 inch
-
Piping - Size (Gas)
-
5/8 inch
-
Piping - Connections Method (Indoor/Outdoor)
-
Flared/Flared
-
Drain Hose Size - O.D, I.D
-
21.5,16.0 mm
-
Between Indoor & Outdoor - Piping Length (Min/Standard/Max)
-
3/7.5/20 m
-
Between Indoor & Outdoor - Piping Length (No Charge)
-
3.5 m
-
Between Indoor & Outdoor - Max. Elevation Difference
-
10 m
-
Refrigerant - Type
-
R410A
-
Refrigerant - Pre Charge
-
1400 g
-
Refrigerant - Additional charge
-
20 g/m
-
Product Type
-
STD
-
Cooling System
-
Cold only
FEATURES
-
Dual Inverter
-
Yes
-
Faster Cooling
-
Yes
-
Less Noise
-
Yes
AIR CARE SYSTEM
-
Auto cleaning
-
Yes
-
Plasmaster Ionizer
-
Yes
