CK500N component-copyModelName
Desktop Thin Client

Key Features

See Retailer for Pricing

Limited Quantity Sale

Available QTY 0
  • vip-price-message
    (CK500N)
    $
    $
    LG Members Price
Total
Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

See Retailer for Pricing

Limited Quantity Sale

Available QTY 0
  • vip-price-message
    (CK500N)
    $
    $
    LG Members Price
Total
Desktop Thin Client
Contact Us
Productivity and Efficiency1 Productivity and Efficiency2
Why Cloud Computing

Productivity and Efficiency

LG offers various Thin Client form factors. LG's excellence in display products can add value to your work environment with better performance and lower costs than a
conventional PC device.
Powerful Compatibility1 Powerful Compatibility2
Simple but Powerful Box

Powerful Compatibility

With LG's CK500N, you can easily transit a multiple monitor environment to a Cloud environment, without requiring too many additional devices.
* Limited to devices supporting 4K resolution.
Silent and <br>Cost-efficient1 Silent and <br>Cost-efficient2
Fanless Design

Silent and
Cost-efficient

The fanless design increases the CK500N's
lifespan and also reduces replacement costs.
The low noise and heat provide a pleasant
office environment, and its lower power
consumption reduces management costs.
Close
PC
  • Processor
    AMD Pairie Falcon GX-212JJ
    Operation System
    Non OS
  • Management Console
    NO
    System Memory
    4GB DDR4
  • Graphics
    Integrated Graphics
    Storage
    32GB (M.2 SSD)
    M.2 2280/2242 SSD Supported (SATA/PCIe supported)
  • Display Support
    4096x2160@50Hz, 3840x2160@60Hz (via DisplayPort 1.2 out)
    4096x2160@24Hz, 3840x2160@30Hz, 2560x1440@60Hz (via HDMI1.4 out)
    1600x1200@60Hz (via DVI out)
    ODD
    NO
  • TPM (Trust Platform Module)
    Software TPM
    Expansion Slot
    M.2 Slots x 2 (Slot 1 : 32GB SSD, Slot 2 : WiFi + Bluetooth card)
    * Note: Slot 1 should be capable of supporting both SATA and PCIe NVMe SSDs.
    SO-DIMM x 1 (Slot 1 : 4GB DDR4)
  • S/W (Pre-Installed App)
    NO
    Certifications
    (Based on US ratings)
    NO
Interface
  • Networking - Wireless
    Intel Dual Band Wireless-AC 3168 1x1 AC (AGN support, BT 4.0 + LE Combo), Extermal Antenna (Dipole)
    Networking - BT
    BT4.0
  • Networking - LAN
    1 x RJ45 : Ehternet 10/100/1000 (Support Wake on LAN)
    Networking - Fiber
    NO
  • Networking - LTE Communication
    NO
    Signal Input - D-Sub
    NO
  • Signal Input - DVI
    NO
    Signal Input - DisplayPort
    NO
  • Signal Input - mini DisplayPort
    NO
    Signal Input - HDMI
    NO
  • Signal Input - Thunderbolt (Ver)
    NO
    Signal Input - DC-in
    YES
  • Signal Input - [ Jack Location ]
    Horizontal
    Signal Output - DVI Out
    YES
  • Signal Output - HDMI Out
    YES
    Signal Output - DisplayPort Out
    YES(1.2)
  • Audio Input - PC Audio In
    NO
    Audio Input - Mic In
    YES
  • Audio Input - [ Jack Location ]
    Horizontal
    Audio Output - RCA
    NO
  • Audio Output - Headphone Out
    YES
    Audio Output - Line-out
    NO
  • Audio Output - Optical out
    NO
    Audio Output - [ Jack Location ]
    Horizontal
  • USB
    4 x USB2.0, 2 x USB3.0
    DC-in
    YES
Speaker
  • Type
    NO
    Audio output (watt)
    NO
Power
  • Type
    Adapter
    Input
    100~240V (50/60Hz)
  • Output
    48 Watt
    Battery
    N/A
  • Consumption - Sleep Mode(Max)
    1.0Watt
    Consumption - DC Off(Max)
    0.6Watt
  • Consumption - Long Idle(Display OFF)
    6.0Watt
    Consumption - Short Idle(Display ON)
    10Watt
  • Consumption - TEC (kWh)
    41.4 kWh
Control Key
  • Key Number
    1
    Key Description
    Power
  • Key Type
    Tact
    LED Color(On mode)
    White (PC Power / HDD)
  • LED Color(Power save mode)
    LED OFF
    [ Key Location ]
    Front
Special Feature
  • PC Features - Webcam
    NO
    PC Features - SD Card Slot
    NO
  • PC Features - Etc.
    NO
    Picture - Picture Mode
    NO
  • Picture - Ratio
    NO
    Picture - PBP / PIP
    NO
  • Picture - Reader Mode
    NO
    Sound - Maxx Audio
    NO
  • General Function - sRGB
    NO
    General Function - DDC/CI
    NO
  • General Function - HDCP
    NO
    General Function - Intelligent Auto (Auto Adjustment)
    NO
  • General Function - Remote Control
    NO
    General Function - Key Lock
    NO
  • General Function - Plug & Play
    NO
    General Function - Response Time
    NO
  • Special Feature - Color Calibrated
    NO
    Special Feature - Dual Control
    NO
  • Special Feature - Dual Smart Solution (Dual web, Dual Display, Smart Resolution )
    NO
    Special Feature - Flicker safe
    NO
  • Special Feature - Motion Energy Saver
    NO
    Special Feature - Off Timer
    NO
  • Special Feature - SIX Axis Control
    NO
    Special Feature - Smart Energy Saving
    NO
  • Special Feature - Super Resolution+
    NO
    Special Feature - True Color Pro / Finder
    NO
  • Special Feature - OSC (On Screen Control / Screen Split)
    NO
    Special Feature - Power Charge
    NO
  • Special Feature - Touch
    NO
Color
  • Front
    Matt Black (Texture)
    Back Cover
    Matt Black (Texture)
  • Stand
    N/A
    Base
    N/A
Security
  • Kenshinton Lock Slot
    YES
Size/Weight
  • Dimension (WxDxH) - Set (with Stand, mm)
    N/A
    Dimension (WxDxH) - Set (without Stand, mm)
    180mm x 39.9mm x 117mm
  • Dimension (WxDxH) - Box (mm)
    231mm x 81mm x 179mm
    Dimension (WxDxH) - VESA / Wall Mount (mm)
    100 x 100, 75 x 75 (wall mount)
  • Weight - Set (without Stand, Kg)
    1kg
    Weight - Box (Kg)
    1.85kg
  • Stuffing - Pallet(20ft/40ft/40ft HC)
    2,500/5,250/-(Air), 3,000/6,300/-(Vessel)
Wrap
  • Packing Material
    A-Flute
    Stacking Type
    Vertical
  • Stand Packing Type
    NO
    Box Printing Type
    Flexo
  • Handle
    NO
Standard
  • IEC60601
    NO
    TCO (Ver.)
    NO
  • UL(cUL)
    YES
    TUV-GS
    YES
  • TUV-Ergo
    YES
    TUV-Type
    YES
  • CB
    YES
    FCC-B
    YES
  • CE
    YES
    CCC (for China)
    N/A
  • BSMI (for Taiwan)
    N/A
    EPA
    NO
  • ISO 9241-307
    NO
    EPEAT
    NO
  • Windows
    NO
    DisplayPort
    NO
  • ROHS, REACH
    ROHS, REACH
    Wi-Fi
    NO
  • Bluetooth
    NO
    PVC-Free
    NO
Accessory
  • Power Adapter
    YES
    Power Cord
    YES
  • D-Sub
    NO
    DVI-D
    NO
  • DisplayPort
    NO
    HDMI
    NO
  • USB
    NO
    PC Audio
    NO
  • CD (Manual / Software)
    YES(Paper Manual)
    Easy Setup Guide
    NO
  • External Calibrator
    NO
    VESA Bracket
    YES
  • External Antenna (Wi-Fi)
    YES
    DVI to VGA Gender
    YES
  • HDMI to VGA Gender
    NO
    RJ45 Gender
    NO
  • Input Device
    NO
ETC
  • Warranty
    3 Years
    Temperature Range
    Operating : 10°C ~ 40°C
    Storage : -20°C ~ 60°C
  • Humidity Range
    Operating : 20%~80%
    Storage : 10%~90%
  • Datasheet
    • LG Thin Client_CK500W-500N Flyer.pdf

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
