24LV761H (EU) component-copyModelName
LV761H Series

Key Features

component-OBScountrySelectDesc

LV761H Series
Display
  • Type
    Edge LED
    Resolution
    1,366 x 768 (HD)
  • Brightness
    250
Broadcasting System
  • Analog
    PAL / SECAM
    Digital
    DVB-T2/C/S2
Video
  • Picture Engine
    XD Engine
    Real Cinema 24p (3:3 Pull down)
  • Aspect Ratio
    • 6 modes (16:9, Original, Full wide, 4:3, Vertical Zoom, All-Direction Zoom)
Audio
  • Audio Output / Speaker System
    5W + 5W / 2.0 ch
    Sound Mode
    • 6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)
Solution
  • Type
    Pro:Centric Smart, V, Direct
    Data Streaming (IP &RF)
  • RF
    • (1 Tuner)
    HCAP (SDK)
    GEM / Flash /HTML5
  • Pro:Centric Application
    PCA 3.7
    Digital Right Management
    Pro:Idiom
Smart Features
  • Smart UX
    webOS 3.5, Commercial Smart Home, Web Browser, Pre-loaded Apps, SDP (Service Delivery Platform) compatibility
    Connectivity
    SoftAP, WiFi (ac), ScreenShare (Miracast), SmartShare, DIAL, Bluetooth Sound Sync, LG Sound Sync
Feature
  • Installation
    EzManager, USB Cloning
    Management
    Wake on RF, WOL, Remote Diagnostics, TVLink Interactive, IR Out, Multi IR Code, HTNG/HDMI-CEC
  • Hospitality
    Hotel Mode, Lock Mode, Welcome Screen, Insert Image, External Speaker Out, Instant ON, One Channel Map, External Power, RJP Compatibility, webRTC Ready
Interface
  • Side
    Headphone Out, HDMI In, USB, CI slot
    Rear
    RF In (2), AV In, Video Component In (Phone Jack Type), Digital Audio Out (Optical), HDMI Input, USB, RS-232C (Control&Service), RJ45, External Speaker Out (2)
Dimension(Unit: mm)
  • Vesa
    75 x 75
    W x H x D / Weight (with stand)
    556 x 384.3 x 140.6 / 3.7 kg
  • W x H x D / weight (packing)
    700 x 140 x 402 / 4.9 kg
General
  • Region
    Europe
  • Datasheet
    • LV761H_EU_CIS_page_0906_171010.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
