32LV541H (ASIA) component-copyModelName
LV541H Series

Key Features

Choose your Size

component-OBScountrySelectDesc

LV541H Series
Display
  • Type
    Direct LED
    Resolution
    1,366 x 768 (HD)
Broadcasting System
  • Analog
    PAL/SECAM
    Digital
    DVB-T2/C (Varied by Countries)
Video
  • Picture Engine
    Triple XD Engine
    Real Cinema 24p (3:3 Pull down)
  • Aspect Ratio
    • 6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan)
Audio
  • Audio Output / Speaker System
    5W + 5W / 2.0 ch
    Sound Mode
    • 6 modes (Standard, Cinema, Clear Voice, Soccer, Music, Game)
Solution
  • Type
    Pro:Centric V, Quick Menu (TV Embedded Home UI)
    Data Streaming (IP &RF)
    • (RF Only)
  • RF
    • (1 Tuner)
    HCAP (SDK)
    GEM / Flash
  • Pro:Centric Application
    PCA 3.7
FEATURES
  • Installation
    EzManager, USB Cloning
    Management
    Wake on RF, Self Diagnostics, TVLink Interactive, IR Out, Multi IR Code, HTNG/HDMI-CEC
  • Hospitality
    Hotel Mode, Lock Mode, Welcome Screen/Video, Insert Image, One Channel Map, External Speaker Out, Instant ON, External Power, RJP Compatibility, External Clock, USB Auto Playback, Time Scheduler
Interface
  • Side
    HDMI In (2), USB, CI Slot
    Rear
    RF In, AV In, Component In (RCA5), Digital Optical Audio Out, HDMI Input, RS-232C (Control & Service), Headphone Out, Clock Interface (RJ12), RJ45 (SNMP), External Speaker Out (2)
Dimension(Unit: mm)
  • Vesa
    200 X 200
    W x H x D / Weight (with stand)
    739 x 495 x 241 / 6.1kg
  • W x H x D / weight (packing)
    905 x 530 x 162 / 7.4kg
General
  • Region
    ASIA
  • Datasheet
    • LV541H_ASIA_fin_page 170925.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
