32LX774M (NA) component-copyModelName
LX774M Series

Key Features

component-OBScountrySelectDesc

LX774M Series
Panel
  • Size
    32” class (31.8" diag)
    Backlight Type
    LED-L
  • Resolution
    1920 x 1080 (FHD)
Broadcasting System
  • Analog
    Yes (NTSC)
    Digital
    Yes (ATSC)
Video
  • Triple XD Engine
    Yes
    Real Cinema 24p (3:3 Pull down)
    Yes
  • Aspect Ratio
    Yes 6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan)
Audio
  • Audio Output / Speaker System
    5W + 5W / 2.0 ch
    Sound Mode
    Yes 6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)
Side Interface
  • HDMI In
    2 (1.4)
    USB (2.0)
    1
Rear Interface
  • RF In
    1
    AV In
    1
  • Digital Audio Out (Optical)
    1
    USB 2.0
    1
  • RS-232C(D-Sub 9pin)
    1 (Service Only, 3.5mm Phone Jack)
    LAN Port
    1
  • External Speaker Out (3.5mm phone jack)
    1 (3.5mm Phone Jack)
    Pillow Speaker interface
    1 (6pin)
  • TV link Configuration
    1 (3.5mm Phone Jack)
    PTC Configuration
    1 (3.5mm Phone Jack)
  • MPI Jack
    1 (RJ-12)
Dimension
  • W x H x D / weight
    28.9" x 17.2" x 2.2" / 11.7 lbs
    W x H x D / weight (Carton)
    31.5" x 20.1" x 4.5" / 14.6 lbs
General
  • Region
    North America
  • Datasheet
    • LG_SPEC-SHEET_LX774M_021706_PR.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
