49UU761H (ASIA) component-copyModelName
49'' UHD Commercial TV

Key Features

Choose your Size

component-OBScountrySelectDesc

49" UHD Commercial TV
Display
  • Backlight Type
    LED (Edge)
    Resolution
    3,840 x 2,160 (4K UHD)
  • Brightness (cd/m²)
    400
    Viewing Angle Degree
    178 x 178
Broadcasting System
  • Analog
    • (PAL/SECAM)
    Digital
    DVB-T2/C (Varied by countries)
Video
  • XD Engine
    Aspect Ratio
    • 6 modes (TBD)
    (16:9, Original, Full wide, 4:3, Vertical Zoom, All-Direction Zoom)
Audio
  • Audio Output
    10W + 10W
    Speaker System
    2.0 ch
  • Sound Mode
    • 6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)
    • 6 modes (India, Australia, Newzeland, Srilanka) (Standard, Cinema, Clear Voice III, Cricket, Music, Game)
    Clear Voice
    • (Clear VoiceⅢ)
Hospitality Solution
  • Solution Type
    Pro:Centric (Smart, V, Direct), Quick Menu 2.0
    Data Streaming (IP & RF)
  • RF
    • (1 Tuner)
    HCAP (SDK)
    GEM / Flash / HTML5
  • Pro:Centric Application
    PCA 3.8 (TBD)
Feature
  • Hospitality
    Hotel Mode, Lock Mode, Welcome Screen, Insert Image, One Channel Map, External Speaker Out, Instant ON, External Power, V-Lan Tag, RJP Interface, RJP Compatibility, External Clock Compatibility, Clock (World Clock / Alarm), 360 Viewer, Auto Off / Sleep Timer, Smart Energy Saving, Motion Eye Care, Teletext / Auto Teletext (Australia 16:9 only), Conformal Coating
Jack Interface
  • Set Side
    HDMI In, USB 2.0 (2), CI Slot
    Set Rear
    RF In, AV In, Component In (Phone Jack Type), Digital Audio Out (Optical), HDMI / HDCP Input, RS-232C (Control & Service), Headphone Out, Clock Interface (RJ12), External Speaker Out
Dimension(Unit: mm)
  • Vesa
    300 x 300
    W x H x D / Weight (with stand)
    1,102 x 698 x 303 / 16.3kg
  • W x H x D / Weight (without stand)
    1,102 x 644 x 36.6 / 13kg
    W x H x D / Weight (Packing)
    1,192 x 737 x 190 / 19.6kg
Power(Unit : Watts)
  • Voltage, Hz
    100~240V, 50 / 60 Hz
    Max
    155.7
  • Typical
    131.6
    Energy saving (Min / Med / Max)
    90 / 65 / 40
  • Stand-by
    0.5W↓
General
  • Region
    ASIA
  • Dimension
    • [Dimension] 49UU761H (ASIA).dwg
    • [Dimension] 49UU761H (ASIA).dxf
    • [Dimension] 49UU761H (ASIA).pdf
  • Datasheet
    • UU761H_ASIA_1005.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
