49UV570H (NA) component-copyModelName
UV570H Series

Key Features

Choose your Size

component-OBScountrySelectDesc

UV570H Series
Display
  • Diagonal Size
    48.5"
    Type
    Direct LED
  • Resolution
    3,840 x 2,160 (4K UHD)
Broadcasting System
  • Analog
    NTSC
    Digital
    ATSC / VSB / Clear QAM
Video
  • XD Engine
    Real Cinema 24p (3:3 Pull down)
  • Picture Mode
    • 9 modes (Vivid, Standard, APS (Eco), Cinema, Sports, Game, HDR Effect, Expert (Bright Room), Expert (Dark Room))
    Aspect Ratio
    • 6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan)
  • HDR
    HDR10
Audio
  • Audio Output / Speaker System
    10W + 10W / 2.0 ch
    Sound Mode
    • 6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)
Feature
  • Installation
    EZ-Manager Wizard (for Initial Configuration), USB Cloning
    Management
    Wake on RF, Remote Diagnosis, TVLink Interative, IR Out (MPI Jack / RS232C), Multi IR Code
  • Hospitality
    Installer Menu, Welcome Screen (Splash Image), Logical Channel Map (LCM), External Speaker Out, Instant On, RJP Compatibility, b-LAN™ embedded
Interface
  • Side
    HDMI (2), USB 2.0
    Rear
    RF In, AV In, Digital Optical Audio Out, HDMI Input, RS-232C (Control & Service), RJ45(2), TV link Configuration (Phone Jack Type), External Speaker Out, MPI Port, Debug
Dimension
  • Vesa (mm)
    300 x 300
    W x H x D / Weight (without stand)
    43.6" x 25.4" x 2.8" / 24.9lb
  • W x H x D / weight (with stand)
    43.6" x 27.6" x 11.9" / 32.1lb
    W x H x D / weight (Carton)
    51.0" x 30.3" x 6.7" / 39.2lb
General
  • Region
    North America
  • Datasheet
    • SPEC_UV570H_101708_PR.PDF
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
