49UV661H (EU) component-copyModelName
UV661H Series

Key Features

component-OBScountrySelectDesc

UV661H Series
Display
  • Type
    Direct LED
    Resolution
    3,840 x 2,160 (4K UHD)
  • Brightness
    400
Broadcasting System
  • Analog
    PAL / SECAM
    Digital
    DVB-T2/C/S2
Video
  • Picture Engine
    XD Engine
    Real Cinema 24p (3:3 Pull down)
  • Aspect Ratio
    • 6 modes (16:9, Original, Full wide, 4:3, Vertical Zoom, All-Direction Zoom)
Audio
  • Audio Output / Speaker System
    10W + 10W / 2.0 ch
    Sound Mode
    • 6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)
Solution
  • Type
    Pro:Centric Smart, V, Direct
    Data Streaming (IP &RF)
  • RF
    • (1 Tuner)
    HCAP (SDK)
    GEM / Flash /HTML5
  • Pro:Centric Application
    PCA 3.7
Smart Features
  • Smart UX
    webOS 3.5, Commercial Smart Home, Web Browser, Pre-loaded Apps, SDP (Service Delivery Platform) compatibility, Magic Remote Ready
    Connectivity
    SoftAP, WiFi (ac), ScreenShare (Miracast), SmartShare, DIAL, Bluetooth Sound Sync, LG Sound Sync
Feature
  • Installation
    EzManager, USB Cloning
    Management
    Wake on RF, WOL, SNMP, Remote Diagnostics, TVLink Interactive, IR Out, Multi IR Code, HTNG/HDMI-CEC
  • Hospitality
    Hotel Mode, Lock Mode, Welcome Screen, Insert Image, External Speaker Out, Instant ON, One Channel Map, External Power, RJP Compatibility, External Clock Compatibility, RTC (Real Time Clock), webRTC Ready
Interface
  • Side
    HDMI In, USB 2.0, USB 3.0, CI Slot
    Rear
    RF In (2), AV In, Video Component In (Phone Jack Type), Digital Audio Out (Optical), HDMI Input, RS-232C In (Control & Service), Headphone Out, Clock Interface, RJ45 (2), External Speaker Out (2)
Dimension(Unit: mm)
  • Vesa
    300 x 300
    W x H x D / Weight (with stand)
    1,110 x 705 x 303 / 14.5kg
  • W x H x D / weight (packing)
    1,296 x 770 x 171 / 17.2kg
General
  • Region
    Europe
  • Datasheet
    • UV661H_EU_CIS_page.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
