49UX970H (NA) component-copyModelName
UX970H Series

Key Features

component-OBScountrySelectDesc

UX970H Series
LCD Panel Specification
  • Backlight Type
    Edge
    Cinema 3D
    -
  • Resolution
    3,840 x 2,160 (UHD)
    Brightness (cd/m²)
    400
Broadcasting System
  • Analog
    NTSC
    Terrestrial
    VSB
  • Cable
    Clear QAM
    Satellite
    -
Video
  • Real Cinema 24p (3:3 Pull down)
    Yes
    Aspect Ratio
    6 modes (16:9, Just scan, Set by program, 4:3, Zoom, Cinema zoom1)
Audio
  • Audio Output
    12W + 12W
    Wireless Sound Sync
    -
Feature
  • Pro:Centric
    Yes (Smart)
    Pro:Idiom
    Yes
Interface - Set Side
  • Headphone Out
    -
    RF In
    -
  • S-Video In
    -
    AV in
    -
  • RGB In (D-sub 15pin)
    -
    Component In (Y,Pb,Pr)
    -
  • PC Audio Input
    -
    HDMI In
    2 (2.0)
  • USB (2.0)
    1 (3.0)
    CI Slot
    -
Interface - Set Rear
  • RF In
    1
    AV In
    1 (Sharing with Component in)
  • AV Out
    -
    S-Video In
    -
  • Full Scart
    -
    Component in (Y,Pb,Pr) + Audio
    1
  • Digital Audio Out (Coaxial / Optical)
    1 (Optical)
    USB 2.0
    1 (2.0)
  • HDMI/HDCP Input
    1 (2.0)
    RGB In (D-sub 15pin) - PC
    -
  • PC Audio Input
    1 (Sharing with Component Audio in)
    RS-232C (D-sub 9pin)
    1 (Phone Jack)
  • Headphone Out
    -
    Clock Interface (D-sub 15pin)
    -
  • LAN Port
    2
    RJ45 (RJP interface)
    1
  • External Speaker Out (3.5mm phone jack)
    1
    TV link Configuration (phone jack type)
    1
Power
  • Voltage, Hz
    100 ~ 240V, 50/60Hz
    Typical (Watts)
    59.7W
Tool Description
  • Swivel (angle)
    -
    VESA Compatibility
    300 X 300
Required Listing(Certification)
  • Safety
    UL
    EMC
    FCC
  • ETC.
    RoHS, cUL, NOM, Energy Star 7.0
Dimension
  • Set Size (W/O Stand, WxHxD, mm)
    1,095.1 X 649.5 X 51.3
    Set Size (With Stand, WxHxD, mm)
    1,095.1 X 699 X 260.6
General
  • Region
    North America
  • Dimension
    • [Drawing]49UX970H_49UF85.dwg
    • [Drawing]55UX970H_55UF8500.dwg
    • [Drawing]65UX970H_65UF85.dwg
    • [Drawing]49UX970H_49UF85.pdf
    • [Drawing]55UX970H_55UF8500.pdf
    • [Drawing]65UX970H_65UF85.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
