55UT570H (NA) component-copyModelName
55'' NanoCell Hotel TV

Key Features

Choose your Size

component-OBScountrySelectDesc

55" NanoCell Hotel TV
Display
  • Inch
    55"
    Resolution
    3,840 x 2,160 (UHD)
  • Backlight Unit Type
    Direct
    Brightness (nit)
    400
Broadcasting System
  • TV Reception
    ATSC, Clear QAM, Analog NTSC
Video
  • HDR (Dolby Vision / 10 Pro / HLG)
    No / Yes / Yes
Audio
  • Audio Output
    10W + 10W
    Speaker System
    2.0 ch
Hospitality Solution
  • Solution Type
    Pro:Centric (Direct, V)
    Data Streaming (IP & RF)
    Yes
  • HCAP (GEM/FLASH/HTML)
    ※ Service Carousel (TLL/XML)
    GEM / HTML5
    DRM
    Pro:Idiom (S/W Type, Media)
  • Pro:Centric Server
    PCS400R
FEATURES
  • Hospitality
    EzManager (Simplicity), USB Cloning, Wake on RF, SNMP, Diagnostics (RF Remote), TVLink Interactive(RS-232C, MPI), HTNG-CEC (1.4), Simplink (HDMI-CEC, 1.4), IR Out, Multi IR Code, PDM(Installer Menu), Welcome Screen, Insert Image, One Channel Map, External Speaker Out, Instant ON, RJP (Remote Jack Pack) Compatibility, Auto Off / Sleep Timer, Motion Eye Care, b-LAN embedded, Anti-theft System (Kensington Lock, Credenza / Security Screw Hole (Except 65"), Lock Down Plate (Except 65")), Chromecast Dongle Anti-theft Cover Optional (Except 43")
Jack Interface
  • Set Side
    HDMI In 2.0 (2), USB (2.0)
    Set Rear
    HDMI In (HDCP, 2.0), RF In (Single b-LAN), AV In (Phone Jack Type), Digital Audio Out (Optical), RS-232C (Control & Service), RJ45 : 2 (RJP Interface, Pro:Centric), External Speaker Out (Spk-out & Line Out), TV link Configuration (Phone Jack Type, b_LAN Service), MPI Port, Debug (Phone Jack Type, CPU/PTC)
Dimension(Unit: mm/kg)
  • Vesa
    300 x 300
    W x H x D / Weight (with stand)
    1,244 x 780 x 303 / 17.5 kg
  • W x H x D / Weight (without stand)
    1,244 x 726 x 87.1 (87.1) / 14.3 kg
    W x H x D / Weight (Shipping)
    1,410 x 860 x 207 / 23.2 kg
Power(Unit : Watts)
  • Voltage, Hz
    120, 50 / 60
    Typical
    144W
  • Stand-by
    Under 0.5W
General
  • Region
    North America
  • Dimension
    • [Dimension] 55UT570H (NA).dwg
    • [Dimension] 55UT570H (NA).pdf
  • Datasheet
    • UT570H(NA)_Datasheet(low)_LG Hotel TV_200204.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
