65LX540S (NA) component-copyModelName
LX540S Series

Key Features

component-OBScountrySelectDesc

LX540S Series
LCD Panel Specification
  • Backlight Type
    LED (Edge)
    Cinema 3D
    -
  • Resolution
    1,920 X 1,080 (FHD)
    Brightness (cd/m²l, Typ)
    350
Broadcasting System
  • Analog
    NTSC
    Terrestrial
    ATSC
  • Cable
    Clear QAM/VSB
Video
  • Aspect Ratio
    6 modes (16:9, Just scan, Set by program, 4:3, Zoom, Cinema zoom1)
Audio
  • Audio Output
    10W + 10W
    Wireless Sound Sync
    -
Feature - Pro:Centric
  • Type
    -
    Hybrid Streaming (IP & RF)
    -
  • Pro:Centric Application
    -
    RF (1/2 Tuner)
    -
  • HCAP (GEM/FLASH/HTML)
    -
Interface - Set Side
  • HDMI In
    1
    USB (2.0/3.0)
    Yes (2, 2.0)
  • CI Slot
    -
    Headphone Out (3.5mm Phone Jack)
    -
  • AV In
    -
Interface - Set Rear
  • RF In
    1
    AV In (Composite)
    1 (Sharing with Component in)
  • Component In (Y, Pb,Pr) + Audio (L/R)
    Yes (1)
    Digital Audio Out (Optical)
    Yes (1)
  • RGB In (D-sub 15pin)
    Yes (1)
    Clock Interface (D-sub 15pin)
    -
  • PC Audio Input
    1 (Sharing with Component in)
    USB (2.0/ 3.0)
    -
  • RS-232C (D-sub 9pin)
    1
    LAN (RJ45)
    Yes (1)
  • Headphone Out (3.5mm Phone Jack)
    -
    Full Scart
    -
  • Ext SPK out (3.5mm Phone Jack)
    Yes (1)
    TV link Configuration (phone jack type)
    -
Power
  • Voltage, Hz
    110 ~ 240V, 50/60Hz
    Typical (Watts)
    142.9W
Tool Description
  • Swivel (angle)
    -
    VESA Compatibility
    300 X 300
Required Listing(Certification)
  • Safety
    UL, FCC
    ETC.
    cUL, NOM, Energy Star 7.0
Dimension
  • WxHxD (w/o stand, mm)
    1,461 X 848 X 39 (SPK 57.3)
    WxHxD (with stand, mm)
    1,461 X 899 X 294
General
  • Region
    North America
  • Dimension
    • [Dimension] 49LF63_with fixed 1pole stand (LX3_LX5_LX7).dwg
    • [Dimension] 55LF63_with fixed 1pole stand (LX3_LX5_LX7).dwg
    • [Dimension] 60LF63_with fixed 1pole stand (LX3_LX5).dwg
    • [Dimension] 65LF63_with fixed 1pole stand (LX3_LX5_LX7).dwg
    • [Dimension] 49LF63_with fixed 1pole stand (LX3_LX5_LX7).pdf
    • [Dimension] 55LF63_with fixed 1pole stand (LX3_LX5_LX7).pdf
    • [Dimension] 60LF63_with fixed 1pole stand (LX3_LX5).pdf
    • [Dimension] 65LF63_with fixed 1pole stand (LX3_LX5_LX7).pdf
