65UW660H (NA) component-copyModelName
UW660H Series

Key Features

component-OBScountrySelectDesc

UW660H Series
Display
  • Diagonal Size
    64.8"
    Type
    Edge LED
  • Resolution
    3,840 x 2,160 (UHD)
Broadcasting System
  • Analog
    NTSC
    Digital
    ATSC/ VSB / Clear QAM
Video
  • Aspect Ratio
    6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan)
Audio
  • Audio Output / Speaker System
    10W + 10W / 2.0 ch
    Sound Mode
    6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)
Interface
  • Side
    HDMI In (2), USB 2.0
    Rear
    RF In, AV In, Optical Digital Audio Out, HDMI Input, USB 2.0, PC Audio Input (Sharing with AV In), RS-232C, LAN Port, RJP port, External Speaker Out, PTC Service Port, Service Port, MPI Port
Dimension
  • Bezel Width (L/R, U, B): on bezel based
    11.6, 14.1, 15.9 (mm)
    Bezel Width (L/R, U, B): off bezel based
    8.6, 11.6, 13.4 (mm)
  • Vesa (mm)
    300 x 300
    WxHxD / weight (w/o stand)
    57.5" x 33.3" x 2.4" / 59.1lb
  • WxHxD / weight (with stand)
    57.5" x 35.4" x 10.4" / 60.8lb
    WxHxD / weight (Carton)
    63.0" x 38.2" x 6.9" / 75.4lb
General
  • Region
    North America
  • Datasheet
    • UW660H_NA_low_170517.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
