10SM3TB component-copyModelName
SM3TB Series

Key Features

Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

SM3TB Series
Contact Us
Close
Panel
  • Screen Size
    10" (10.1")
    Resolution
    1,280 x 800 (HD)
  • Brightness(Module, Typ., cd/m²)
    450
Connectivity - Intput
  • HDMI
    No
    DVI-D
    No
  • DP
    No
    Analog (RGB)
    No
  • Audio In
    No
    External Control (RS232C IN)
    No
  • External Control (RJ45)
    Yes (1)
    External Control (IR receiver)
    No
  • External Control (Pixel Sensor)
    No
    USB (USB2.0)
    Yes (1)
  • SD Card (SDHC/Full Size)
    Yes (micro SD)
Connectivity - Output
  • Audio Out
    No
    Externel Speaker Out
    No
  • External Control (RS232C OUT)
    No
Physical Specification
  • Bezel Width
    14mm (T,R/L,B)
    Monitor Dimension (W x H x D)
    245.6mm X 164.2mm X 29.7mm
  • Weight (Head)
    0.63kg
    VESA™ Standard Mount Interface
    50mm x 50mm
Media Player Compatibility
  • OPS type compatible
    No
    External Media player Attatchable
    No
Software Compatibility
  • SuperSign-w lite
    No
    SuperSign-c
    No
Accessory
  • Basic
    Adaptor, Manual (Web), ESG
    Optional
    SP-2000, ST-200T, LSW430
General
  • Region
    Global
  • Dimension
    • 10SM3TB_Drawing.dwg
    • 10SM3TB_Drawings.pdf
  • Datasheet
    • [Leaflet] 10SM3TB_Leaflet_151202.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
