LS33A Series

Key Features

component-OBScountrySelectDesc

LS33A Series
Panel
  • Screen Size
    42"
    Resolution
    1,920 x 1,080 (FHD)
  • Brightness
    300
Connectivity - Intput
  • Digital
    HDMI(1)
    Analog
    RGB(1)
  • Audio
    Yes (1)
    External Control
    RS232C (1), RJ45 (1), IR Receiver (1)
  • USB
    Yes (1)
Connectivity - Output
  • Audio
    Speaker L/R
    External Control
    RS232C(1)
Physical Specification
  • Bezel Width
    8.5mm (T/L/R), 14mm (B)
    Monitor Dimension (W x H x D)
    959.5 x 559 x 55.5 mm
  • Weight (Head)
    9.1kg
    VESA™ Standard Mount Interface
    400mm x 400mm
Environment Conditions
  • Operation Temperature
    0°C to 40°C
    Operation Humidity
    10 % to 80 %
Power
  • Power Supply
    100-240V~, 50/60Hz
    Power Switch
    No
Power Consumption
  • Typ.
    70W
    Smart Energy Saving
    45W (Typ)
  • DPM
    0.5W (RGB), 0.7W (HDMI)
    Power off
    0.5 W
Standard(Certification)
  • Safety
    UL / cUL / CB / TUV / KC
    EMC
    FCC Class "A" / CE / KCC
  • ErP / Energy Star
    Yes / Yes (Energy Star 6.0)
Media Player Compatibility
  • Slot PC compatible (optional)
    No
    External Media player Attatchable
    Yes (MP500/MP700)
Software Compatibility
  • SuperSign-w lite
    Yes
    SuperSign-c
    Yes
Accessory
  • Basic
    Remote Controller (include battery 2ea), Power Cord, IR Receiver, CD (Owner’s Manual, SuperSign Program / Manual), RGB Cable
    Optional
    SP-2100 (External Speaker), ST-421T, LSW440S, AN-WF500 (Wi-Fi USB Dongle)
  • Dimension
    • [Dimension] 42LS33A_LS35A_LS53A_LS55A.dwg
    • [Dimension] 42LS33A_LS35A_LS53A_LS55A.pdf
  • Datasheet
    • [Leaflet] LS33A_(preview)_150924.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
