43LX310C (ASIA) component-copyModelName
LX310C Series

Key Features

component-OBScountrySelectDesc

LX310C Series
LCD Panel Specification
  • Backlight Type
    Direct LED
    Cinema 3D
    -
  • Resolution
    1,920 X 1,080 (FHD)
    Brightness (cd/m²l, Typ)
    200
Broadcasting System
  • Analog
    PAL/NTSC-M
    Terrestrial
    DVB-T2
  • Cable
    DVB-C
    Satellite
    -
Video
  • Real Cinema 24p (3:3 Pull down)
    Yes
    Aspect Ratio
    8 modes (16:9, Just Scan, Original, Full wide, 4:3, 14:9, Zoom, Cinema Zoom 1)
Audio
  • Audio Output
    5W + 5W
    Wireless Sound Sync
    -
Feature
  • Pro:Centric
    -
    Pro:Idiom
    -
Interface - Set Side
  • Headphone Out
    1
    RF In
    -
  • AV In
    -
    S-Video In
    -
  • RGB In (D-sub 15pin)
    -
    Component in (Y,Pb,Pr)
    -
  • PC Audio Input
    -
    HDMI In (HDMI1.4)
    1
  • USB (2.0)
    2
    CI Slot
    -
  • IR Out
    -
Interface - Set Rear
  • RF In
    1
    AV In
    1
  • AV Out
    -
    S-Video In
    -
  • Full Scart
    -
    Component in (Y,Pb,Pr) + Audio
    1 (Commonly used w/AV)
  • Digital Audio Out (Coaxial / Optical)
    1 (Optical)
    HDMI(HDMI1.4)/HDCP Input
    1
  • USB 2.0
    -
    RGB In (D-sub 15pin) - PC
    1
  • PC Audio Input
    1 (Commonly used w/AV)
    RS-232C (D-sub 9pin)
    1
  • Headphone Out
    -
    Clock Interface
    -
  • LAN Port
    -
    RJ45 (RJP interface)
    -
  • External Speaker Out(3.5mm phone jack)
    -
    TV link Configuration (phone jack type)
    -
Power
  • Voltage, Hz
    100 ~ 240V, 50/60Hz
    Typical (Watts)
    60.0W
Tool Description
  • Swivel (angle)
    -
    VESA Compatibility
    200 X 200
Required Listing(Certification)
  • Safety
    CB, BIS, SIRIM, TISI, BPS, PSB, SNI
    EMC
    CISPR
  • ETC.
    MEPS, Tick, EE, CIF, BEE, Freeview
Dimension
  • WxHxD (w/o stand, mm)
    971 X 624 X 39.9 (SPK 58.7)
    WxHxD (with stand, mm)
    971 X 624 X 198
General
  • Region
    ASIA
  • Dimension
    • [Drawing] 49LX310C(ASIA, KOREA)_49LF54.dwg
    • [Drawing]43 LX310C(ASIA, KOREA)_43LF54.dwg
    • [Drawing] 49LX310C(ASIA, KOREA)_49LF54.pdf
    • [Drawing]43 LX310C(ASIA, KOREA)_43LF54.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
