Discontinued
49LS73D component-copyModelName
LS73D Series

Key Features

Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

LS73D Series
Contact Us
Close
Panel
  • Screen Size
    49"
    Resolution
    1,920 x 1,080 (FHD)
  • Brightness(Typ.,cd/m²)
    500
Connectivity
  • Input
    HDMI (2), DP, DVI-D, Audio In, OPS, USB 3.0
    Output
    DP, External Speaker Out
  • External Control
    RS232C in/out, RJ45, IR / Light Sensor, Pixel Sensor
Physical Specification
  • Bezel Width
    7.4 mm (T/L/R/B even)
    Monitor Dimension (W x H x D)
    1,095 x 637 x 32 mm
  • Weight (Head)
    15.6 kg
    VESA™ Standard Mount Interface
    400 x 400
Environment Conditions
  • Operation Temperature
    0°C to 40°C
    Operation Humidity
    10 % to 80 %
Power
  • Power Supply
    100-240 V~, 50/60 Hz
    Power Type
    Built-In Power
Power Consumption
  • Typ.
    105W
    Smart Energy Saving
    75W
Standard(Certification)
  • Safety
    UL / cUL / CB / TUV / KC
    EMC
    FCC Class "A" / CE / KCC
  • ErP / Energy Star
    Yes (EU Only) / Yes (Energy Star 7.0)
Media Player Compatibility
  • OPS type compatible
    Yes
    External Media player Attatchable
    Yes (MP500/MP700)
Software Compatibility
  • Content Management Software
    SuperSign Premium
    Control and Monitoring Software
    SuperSign C
Accessory
  • Basic
    Remote Controller (2ea batteries included), Power Cord, IR / Light Sensor Receiver, QSG, Regular Book (depend on regional standard), HDMI Cable
    Optional
    External Speaker (SP-2100), Stand(ST-200T), Wall Mount(LSW440S), Wi-Fi USB Dongle (AN-WF500), OPS Kits (KT-OPSA), Pixel Sensor (KT-SP0)
  • Dimension
    • 49LS73D.dwg
    • 49LS73D.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
