55LY340C (MEA) component-copyModelName
LY340C Series

Key Features

component-OBScountrySelectDesc

LY340C Series
LCD Panel Specification
  • Cinema 3D
    -
    Resolution
    1,920 X 1,080 (FHD)
Broadcasting System
  • Analog
    PAL/SECAM
    Cable
    DVB-T2/C/S2
Video
  • Aspect Ratio
    8 modes (16:9, Just Scan, Original, Full wide, 4:3, 14:9, Zoom, Cinema Zoom 1)
Audio
  • Audio Output
    10W + 10W
    Wireless Sound Sync
    -
Feature - Pro:Centric
  • Type
    -
    Hybrid Streaming (IP & RF)
    -
  • RF (1/2 Tuner)
    -
    Pro:Centric Application
    -
  • HCAP (GEM/FLASH/HTML)
    -
Interface - Set Side
  • HDMI In
    1
    USB (2.0)
    1
  • CI Slot
    1
    Headphone Out (3.5mm Phone Jack)
    -
  • AV In
    -
Interface - Set Rear
  • RF In
    1
    AV In (Composite)
    -
  • Component In (Y, Pb,Pr) + Audio (L/R)
    1 (Phone Jack)
    Digital Audio Out (Optical)
    1
  • RGB In (D-sub 15pin)
    1
    Clock Interface (D-sub 15pin)
    -
  • PC Audio Input
    1 (Sharing with Component Phone Jack Audio)
    USB (2.0/ 3.0)
    -
  • Headphone Out (3.5mm Phone Jack)
    1
    RS-232C (D-sub 9pin)
    1
  • HDMI In
    1
    LAN (RJ45)
    -
  • Full Scart
    1
    MPI Port(RJ12)
    -
  • Pillow Speaker Interface
    -
    RJP interface (RJ45)
    -
  • Ext SPK out (3.5mm Phone Jack)
    1
    TV link Configuration (phone jack type)
    -
  • PTC Configuration (phone jack type)
    -
Power
  • Voltage, Hz
    100 ~ 240V, 50/60Hz
    Typical (Watts)
    124.0W
Tool Description
  • Swivel (angle)
    -
    VESA Compatibility
    400 X 400
Required Listing(Certification)
  • Safety
    CB, CE
Dimension
  • WxHxD (w/o stand, mm)
    1,243 X 725 X 56.8
    WxHxD (with stand, mm)
    1,243 X 772 X 247
General
  • Region
    Middle East & Africa
  • Datasheet
    • [Leaflet] LY340C (EU, CIS).pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
