55'' 700 nits UHD Signage

Key Features

Choose your Size

component-OBScountrySelectDesc

55" 700 nits UHD Signage
Panel
  • Screen Size
    55"
    Panel Technology
    IPS
  • Aspect Ratio
    16 : 9
    Native Resolution
    3,840 x 2,160 (UHD, RGB)
  • Brightness(Typ.,cd/m²)
    700
    Contrast Ratio
    1,100:1
  • Viewing Angle (H x V)
    178 x 178
    Response Time
    8ms (G to G)
  • Surface Treatment (Haze)
    Haze 3%
    Life Time (Typ.)
    50,000 Hrs
  • Operation Hours
    24 Hrs
    Orientation
    Portrait & Landscape
Connectivity
  • Input
    HDMI (3), DP, DVI-D, Audio, USB 2.0
    Output
    DP, Audio (Off/Fixed/Variable)
  • External Control
    RS232C In/out, RJ45 (LAN) In, IR In
Mechanical Specification
  • Bezel Color
    Black
    Bezel Width
    9.9mm(T/R/L), 14.4mm(B)
  • Monitor Dimensions (W × H × D)
    1,234.4mm x 720.9mm x 39.9mm
    Weight (Head)
    19.0 kg
  • Carton Dimensions (W × H × D)
    1,360mm x 835mm x 175mm
    Packed Weight
    24.2 kg
  • Handle
    No
    VESA™ Standard Mount Interface
    300 x 300
Special Feature
  • Tilt (Facedown)
    Max. 30º *In conditions within 30ºC temperature, 50% humidity
    IP Rating
    IP5x
Environment Conditions
  • Operation Temperature
    0°C to 40°C
    Operation Humidity
    10 % to 80 %
Power
  • Power Supply
    100-240V~, 50/60Hz
    Power Type
    Built-In Power
Power Consumption
  • Typ. / Max.
    110W / 160W
    Smart Energy Saving
    85W
Certification
  • Safety
    CB / NRTL
    EMC
    FCC Class "A" / CE / KC
  • ErP / Energy Star
    Yes (EU Only) / Yes (Energy Star 8.0)
Media Player Compatibility
  • OPS type compatible
    Yes
Software Compatibility
  • Content Management Software
    SuperSign CMS
    Control and Monitoring Software
    SuperSign Control/Control+
  • Signage365Care
    Yes
Accessory
  • Basic
    Remote Controller, Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender
    Optional
    Stand(ST-653T), Media Player, Wall Bracket(LSW350B), VESA Adapter(AM-B330S), OPS Kit (KT-OPSF)
General
  • Region
    Global
  • Dimension
    • [Dimension]55UH7F_UH5F_UM3F.dwg
    • [Dimension]55UH7F_UH5F_UM3F.pdf
  • Datasheet
    • UH7F_Datasheet(low)_LG UHD Signage_200313.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
