Discontinued
86BH5C component-copyModelName
Ultra Stretch Signage

Key Features

Choose your Size

Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

Ultra Stretch Signage
Contact Us
Close
Panel
  • Screen Size
    86"
    Resolution
    3,840 x 600 (UHD)
  • Brightness(Typ.,cd/m²)
    500
Connectivity
  • Input
    HDMI, DP, OPS, DVI-D, USB2.0, USB3.0, SD Card
    Output
    Analog Audio
  • External Control
    RS232C, RJ45, IR+B Receiver, Pixel Sensor, Analog Audio
Physical Specification
  • Bezel Width
    4.4mm (L/R), 5.9mm (T/B)
    Monitor Dimension (W x H x D)
    2,158.3 x 348.5 x 81.7mm
  • Weight (Head)
    20.5kg
Environment Conditions
  • Operation Temperature
    0°C to 40°C
    Operation Humidity
    10 % to 80 %
Power
  • Power Supply
    100-240V~, 50/60Hz
    Power Type
    Built-In Power
Standard(Certification)
  • Safety
    UL / cUL / CB / TUV / KC
    EMC
    FCC Class "A" / CE / KCC
  • ErP / Energy Star
    Yes (EU Only) / NA
Media Player Compatibility
  • OPS type compatible
    Yes
    External Media player Attatchable
    No
Software Compatibility
  • SuperSign-w lite
    Yes
    SuperSign-c
    Yes
Accessory
  • Basic
    Remote Controller (2ea Batteries included), Power Cord, DP (3M), RS-232C Cable (3M), Owner's Manual (Website upload)
    Optional
    AN-WF500 (WiFi USB Dongle), MP700, KT-OPSA (OPS KIT), KT-SP0 (RGB Sensor) ** Stand is not available
  • Dimension
    • 86BH5C.dwg
    • 86BH5C.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
