86UU640C (MEA) component-copyModelName
86'' 350 nits UHD UHD Commercial TV

Key Features

Choose your Size

Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

86" 350 nits UHD UHD Commercial TV
Inquiry to Buy
Close
Panel
  • Screen Size
    86"
    Backlight Type
    Trident
  • Resolution
    3,840 x 2,160 (4K UHD)
    Brightness (cd/m²)
    350
  • Viewing Angle Degree
    178
Broadcasting System
  • Analog
    • (PAL/SECAM)
    Digital
    •
Video
  • XD Engine
    •
    Aspect Ratio
    • 5 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom)
  • HDR 10 / HDR Dolby Vision
    • / -
Audio
  • Audio Output
    10 W + 10 W
    Speaker System
    2.0 ch
  • Sound Mode
    • 6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)
    Clear Voice
    • (Clear VoiceⅢ)
Feature
  • Smart
    webOS 4.0, Commercial Smart Home, Gallery Mode, Web Browser, Pre-loaded App (YouTube Only), Soft AP, Wi-Fi (ac), Screen Share (Miracast), DIAL, Bluetooth Audio Playback, LG Sound Sync/bluetooth, Mobile Connection Overlay, Music Player
    Hospitality
    Hotel Mode / PDM / Installer Menu, Lock mode (Limited), Welcome Screen, Insert Image, One Channel Map, RJP Interface, RJP Compatibility, DPM, Time Scheduler, RTC, NTP Sync Timer, BEACON
Function
  • Function
    USB Cloning, WOL (Magic packet only), SNMP, Diagnostics, HTNG-CEC (1.4), HDMI-CEC (1.4), IR Out, Multi IR Code, Auto Off / Sleep Timer, Smart Energy Saving, Motion Eye Care, USB Auto Playback / USB Auto Playback+, Crestron Connected® (Network Based Control), DPM, Time Scheduler, RTC, NTP Sync Timer, BEACON, Embedded CM & GM
Jack Interface
  • Set Side
    HDMI In 2.0 (2), USB 2.0, CI Slot
    Set Rear
    RF In (2), Digital Audio Out (Optical), HDMI/HDCP Input 2.0, RS-232C (Control & Service), Headphone Out, RJ45, Debug (Phone Jack Type)
Dimension(Unit: mm)
  • VESA Compatible
    600 x 400
    W x H x D / Weight (with stand)
    TBD / TBD
  • W x H x D / Weight (without stand)
    TBD / 44.2 kg
    W x H x D / Weight (Packing)
    TBD / TBD
Power(Unit : Watts)
  • Voltage, Hz
    100 ~ 240 V, 50/60 Hz
    Max
    320.8
  • Typical
    306.4
    Energy saving (Min/Med/Max)
    199 / 130 / 54
  • Stand-by
    0.5↓
General
  • Region
    Middle East & Africa
  • Dimension
    • [Dimension] 86UU640C (MEA).dwg
    • [Dimension] 86UU640C (MEA).pdf
  • Datasheet
    • UU640_MEA_Low_181029.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
