UHD Standard Signage
Inquiry to Buy

LG UHD Large Screen Signage

People sitting in the conference room are looking at the big screen and having a meeting. People sitting in the conference room are looking at the big screen and having a meeting.
* All images in this web page are for illustrative purposes only and may differ from the actual product.
The image compares that one with Non-glare Coating and the other without Non-glare coating. And it shows that a screen with Non-glare Coating can be seen clearly under the light compared to the screen that do not. The image compares that one with Non-glare Coating and the other without Non-glare coating. And it shows that a screen with Non-glare Coating can be seen clearly under the light compared to the screen that do not.
SUPERB PICTURE QUALITY

Clear View with Non-glare Coating

Viewers can be annoyed by unnecessary reflections when watching a screen under brightly lit conditions. The UM3DG-H series has reduced such inconveniences by increasing the level of haze, which enhances visibility and text readability.
* The images listed are for reference only and the actual reflection can be different.
This image illustratively compares FHD resolution and UHD resolution. This image indicates that the screen with UHD has 4 times higher resolution than FHD, so contents can be seen more vivid and colorful. This image illustratively compares FHD resolution and UHD resolution. This image indicates that the screen with UHD has 4 times higher resolution than FHD, so contents can be seen more vivid and colorful.
SUPERB PICTURE QUALITY

ULTRA HD Resolution

With the resolution that is 4 times higher than FHD, it makes the color and details of the contents more vivid and realistic. In addition, the wide viewing angle applied with an IPS panel, provides clear contents.
This image show that several tasks can be done at the same time with the intuitive GUI. This image show that several tasks can be done at the same time with the intuitive GUI.
webOS SMART SIGNAGE

High-Performance with webOS

Built-in Quad Core SoC can execute several tasks at once while providing smooth content playback. Also, LG webOS smart signage platform enhances user convenience with intuitive GUI and provides to SI or/and developers simple app development tools such as SDK (Software Development Kit), SCAP, sample applications.
This image show that several tasks can be done at the same time with the intuitive GUI. This image show that several tasks can be done at the same time with the intuitive GUI.
webOS SMART SIGNAGE

Various Sensor Connection

LG webOS smart signage platform helps to easily provide value-added solutions by supporting simple connections with external sensors* such as GPIO, NFC/RFID, temperature sensors, etc, via USB plug-in.
* External sensors need to be purchased separately and tested for compatibility with webOS platform.
One signage on the wall has the built-in speaker which making the sound rich. One signage on the wall has the built-in speaker which making the sound rich.
USER CONVENIENCE

Built-in Speaker

Contents will be enriched with sound effects from built-in speakers, without the need for purchasing or installing external speakers.
The UM3DG-H series is on the wall and a woman using a personal PC and mobile phone. And this image shows that the signage can be connected wirelessly to the PC and mobile phone she is holding. The UM3DG-H series is on the wall and a woman using a personal PC and mobile phone. And this image shows that the signage can be connected wirelessly to the PC and mobile phone she is holding.
USER CONVENIENCE

Wireless Access Point

The UM3DG-H series operates as a virtual router which can be a wireless access point for mobile devices.
* Maximum 10 units of the mobile devices can be connected via softAP
This is one of meeting room with the signage and one of AV control system which helps users control the UM3DG-H series. This is one of meeting room with the signage and one of AV control system which helps users control the UM3DG-H series.
MEETING ROOM SOLUTION

Compatible with AV Control System

The UM3DG-H series supports Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.
* Network based control
A video conference is being held as people are screened on signage installed on the wall. A video conference is being held as people are screened on signage installed on the wall.
MEETING ROOM SOLUTION

Compatible with Video Conference System

For the optimum visual meeting, the UM3DG-H series supports its compatibility with Cisco System that offers powerful and integrated control* for a smarter video conference.
* Using an HDMI cable connection
This image shows that the content set on the Control Manager and the content displayed on the signage are same. And it indicates that UM3DG-H series can be remotely controlled and monitored in a different place with devices such as a mobile phone and a laptop, through the Control Manager. This image shows that the content set on the Control Manager and the content displayed on the signage are same. And it indicates that UM3DG-H series can be remotely controlled and monitored in a different place with devices such as a mobile phone and a laptop, through the Control Manager.
EASY MANAGEMENT

Mobile & Web Monitoring

Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of the UM3DG-H series displays in different locations in real-time. It is available on internet connected devices, allowing you to flexibly and rapidly respond to emergency situations.
* The mobile devices need be connected with the Signage IP address and can control one Signage at a time.
The LG employee is remotely monitoring the UM3DG-H series installed in a different place. The LG employee is remotely monitoring the UM3DG-H series installed in a different place.
EASY MANAGEMENT

Real-time ConnectedCare Service

Maintenance is easy and fast with the optional ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients' businesses.
* The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately.
So please contact the LG sales representative in your region for more details.
Close
Panel
  • Screen Size
    86
    Panel Technology
    IPS
  • Native Resolution
    3840 x 2160 (UHD)
    Brightness
    350nit (Typ.)
  • Contrast Ratio
    1,100:1
    Dynamic CR
    1,000,000:1
  • Color gamut
    BT709 95%
    Viewing Angle(H x V)
    178x178
  • Color Depth
    10bib, 1.07Billion colors
    Response Time
    8ms (G to G)
  • Surface Treatment(Haze)
    28%
    Operation Hours (Hours/Day)
    24/7
  • Portrait / Landscape
    Yes / Yes
Connectivity
  • Input
    HDMI (3, HDCP2.2/1.4), RS232C IN (1, 4pin Phone-jack), RJ45(LAN), IR IN, USB2.0 Type A
    Output
    Audio Out, RS232C OUT (1, 4pin Phone-jack)
Mechanical Specification
  • Bezel Color
    Black
    Bezel Width
    Even bezel : 14.3mm
  • Weight (Head)
    49.0Kg
    Monitor Dimension(W x H x D)
    1926.2 x 1097.2 x 60.6mm
    (without Handle and LG Logo)
  • Handle
    Yes
    VESA™ Standard Mount Interface
    600 x 400
Environment Conditions
  • Operation Temperature
    0 °C to 40 °C
    Operation Humidity
    10 % to 80 %
Power
  • Power Supply
    AC 100-240V~, 50/60Hz
    Power Type
    Built-In Power
Power Consumption
  • Typ.
    215W (TBD)
    Max.
    280W (TBD)
  • BTU (British Thermal Unit)
    733.69 BTU/Hr(Typ.), 955.5 BTU/Hr(Max) (TBD)
Sound
  • Speaker
    Yes
Certification
  • Safety
    CB / NRTL
    EMC
    FCC Class "A" / CE / KC
  • ErP / Energy Star
    Yes / No
Software Compatibility
  • SuperSign CMS
    Yes
    SuperSign Control / Control+
    Yes / Yes
  • SuperSign WB
    Yes
    SuperSign Media Editor
    Yes
  • LG ConnectedCare
    Yes
Accessory
  • Basic
    Remote Controller., Power Cord, QSG, Regulation Book, Phone to RS232C Gender
    Optional
    LSW640A/B(Wall Mount)
  • Dimension
    • (Dimension) 86um3dg_201125.pdf
  • Datasheet
    • UM3DG-H_Datasheet(low)_LG UHD Signage_210209.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
