LAP025EP Copy Model Name
P2.5 700 nits LG LED Curve Series for Indoor

Key Features

Choose your Pitch

Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

P2.5 700 nits LG LED Curve Series for Indoor
Contact Us
Close
Physical Parameters
  • Pitch Name
    P2.5
    Pixel Configuration
    3 in 1 SMD
  • Pixel Pitch (mm)
    2.50
    Module Resolution (W x H)
    96 x 72
  • Module Dimensions (W x H, mm)
    240 x 180
    Weight per Module (kg)
    0.36
  • No. of Modules per Unit Case (W x H)
    2 x 3
    Unit Case Resolution (W x H)
    192 x 216
  • Unit Case Dimensions (W x H x D, mm)
    480 x 540 x 105
    Unit Case Surface Area (m²)
    0.259
  • Weight per Unit Case (kg/unit)
    10.1
    Weight per Square Meter (kg/m²)
    37.4
  • Physical Pixel Density (pixels/m²)
    160,000
    Flatness of Unit Case (mm)
    ±0.2
  • Unit Case Material
    Die Casting Aluminum
    Service Access
    Front and Rear
Optical Parameter
  • Min. Brightness (After Calibration)
    700 cd/m²
    Color Temperature
    3,200 ~ 9,300
  • Visual Viewing Angle (Horizontal)
    160
    Visual Viewing Angle (Vertical)
    140
  • Brightness Uniformity
    95%
    Color Uniformity
    ±0.015Cx, Cy
  • Contrast Ratio
    6,000
    Processing Depth (bit)
    16 (HDR10)
Electrical Parameter
  • Power Consumption (W/Unit, Max.)
    99
    Power Consumption (W/Unit, Avg.)
    26
  • Power Consumption (W/m², Max.)
    380
    Heat Dissipation (BTU/h/Cabinet, Max.)
    338
  • Heat Dissipation (BTU/h/Cabinet, Avg.)
    89
    Heat Dissipation (BTU/h/m², Max.)
    1,296
  • Power Supply (V)
    100 to 240
    Frame Rate (Hz)
    50 / 60
  • Refresh Rate (Hz)
    3,840
Operation Conditions
  • Lifetime (Hours to Half Brightness)
    50,000
    Operating Temperature (°C)
    0°C to + 40°C
  • Operating Humidity
    10-80% RH
Certification
  • EMC
    FCC Class A / CE / KC
    Environment
    RoHS
Controller
  • Controller
    LCLG005-B
Connectivity
  • Video Inputs
    HDMI In, DP In, OPS In, USB
    Control
    RJ45 In, RS232C In/out
  • Special Features
    HDR10, Temperature Sensor, Power Detection
  • Dimension
    • LAP025EL7B_2D.dwg
    • LAP025EL7N_2D.dwg
    • LAP025EL7B_2D.pdf
    • LAP025EL7N_2D.pdf
  • Datasheet
    • LG Real Curve LED_LAPE series_Datasheet(web)_2008.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
