Key Features

Pixel Pitch: 6.66mm
Brightness: 5,000 cd/m²
Fast Assembly and Easy Maintenance
IP65 Weatherproof Design
90º Corner Option Available

Choose your Pitch

Add to Compare

component-OBScountrySelectDesc

Key Features

Pixel Pitch: 6.66mm
Brightness: 5,000 cd/m²
Fast Assembly and Easy Maintenance
IP65 Weatherproof Design
90º Corner Option Available

Choose your Pitch

Add to Compare

component-OBScountrySelectDesc

component-copyModel-toastMsg

Essential Series

Customizable Screen Ratio

Cabinets of the GSCC series can be assembled to configure any screen size including the 16:9, 8:9 and 4:3 screen ratio. This enables customers to apply LED Screens according to installation sites.

Fast Assembly and Easy Maintenance

The fast lock helps LED modules be simply set up or dismantled. Separate power and control unit design also facilitates easy maintenance.

Front or Rear Serviceability

The product offers either front access or rear access, allowing customers to choose installation options according to their environment and minimizes limitations in installation and maintenance.

90° Corner Design Available

If you add a 90° corner option, the GSCC series can deliver flawless content even when installed on the corners.

IP Rated Weatherproof Design

The front and back of the cabinet are IP65 certified, allowing stable operation unaffected by weather and harmful outdoor environments.

Physical Parameters

Pixel Configuration

3 in 1 SMD

Pixel Pitch (mm)

6.66
Module Resolution (W x H)

48 × 36

Module Dimensions (W x H, mm)

320 × 240
Weight per Module (kg)

1.30

No. of Modules per Cabinet (W × H)

2 × 3
Cabinet Resolution (W × H)

96 × 108

Cabinet Dimensions (W × H × D)

640 × 720 × 112.9
Cabinet Surface Area (m²)

0.461

Weight per Cabinet (kg/cabinet)

17.0
Weight per Square Meter (kg/m²)

36.9

Physical Pixel Density (pixels/m²)

22,500
Flatness of Cabinet

±0.5 mm

Cabinet Material

Die Casting Aluminum
Service Access

Front or Rear (One Option Only)

Optical Parameter

Min. Brightness (After Calibration)

5,000

Color Temperature

3,500 ~ 9,000
Visual Viewing Angle (Horizontal/Vertical)

160 / 120

Brightness Uniformity

97%
Color Uniformity

± 0.003 Cx,Cy

Contrast Ratio

5,000
Processing Depth (bit)

14

Electrical Parameter

Power Consumption (W/Cabinet, Max.)

330

Power Consumption (W/Cabinet, Avg.)

110
Power Consumption (W/m², Max.)

720

Heat Dissipation (BTU/h/Cabinet, Max.)

1,126
Heat Dissipation (BTU/h/Cabinet, Avg.)

375

Heat Dissipation (BTU/h/m², Max.)

2,457
Power Supply (V)

100 to 240

Frame Rate (Hz)

50 / 60
Refresh Rate (Hz)

3,840

Operation Conditions

Lifetime (Hours to Half Brightness)

100,000

Operating Temperature (°C)

-20℃ to +50℃
Operating Humidity

10-99%RH

IP rating Front / Rear

IP65 / IP65

Certification

Certification

CE,FCC,ETL

Environment

Environment

RoHS

Controller

Controller

LCIN006

Dimension
- (2D Drawing)LG GSCCxxx-GN-series.dwg
- (2D Drawing)LG GSCCxxx-GN-series.pdf
Datasheet
- LG Essential LED_GSCC series_Datasheet(web)_2005.pdf
Software

To download Software, Please visit the Software Download Page (Click).
Manual

To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
